Quick Details
-
Positioning Accuracy (mm):
-
0.03 mm
-
Travel (X Axis)(mm):
-
1300 mm
-
Travel (Y Axis)(mm):
-
2500 mm
-
Repeatability (X/Y/Z) (mm):
-
0.03 mm
-
Spindle Motor Power(kW):
-
9
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CNCSUPER
-
Voltage:
-
380V/50HZ/3P
-
Power (kW):
-
9
-
Weight (KG):
-
3000
-
Working area(XY):
-
1300x2500mm
-
Z travel height:
-
200mm, Z axis with coupling
-
Positional accuracy:
-
±0.03/300mm
-
Spindle power:
-
9KW ATC air cooling spindle
-
NO. of revolution:
-
24000rpm/min
-
X.Y.Z axis rail:
-
Taiwan HIWIN guiding rail
-
Motor and drive:
-
Taiwan SYNTEC servo motors and drives
-
Lubrication:
-
ATC lubrication
-
Max Cutting Speed:
-
35000mm/min
Quick Details
-
Working Table Size(mm):
-
1300×2500
-
Machine Type:
-
CNC Router
-
Range of Spindle Speed(r.p.m):
-
1 - 24000 rpm
-
Positioning Accuracy (mm):
-
0.03 mm
-
Travel (X Axis)(mm):
-
1300 mm
-
Travel (Y Axis)(mm):
-
2500 mm
-
Repeatability (X/Y/Z) (mm):
-
0.03 mm
-
Spindle Motor Power(kW):
-
9
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CNCSUPER
-
Voltage:
-
380V/50HZ/3P
-
Power (kW):
-
9
-
Weight (KG):
-
3000
-
Working area(XY):
-
1300x2500mm
-
Z travel height:
-
200mm, Z axis with coupling
-
Positional accuracy:
-
±0.03/300mm
-
Spindle power:
-
9KW ATC air cooling spindle
-
NO. of revolution:
-
24000rpm/min
-
X.Y.Z axis rail:
-
Taiwan HIWIN guiding rail
-
Motor and drive:
-
Taiwan SYNTEC servo motors and drives
-
Lubrication:
-
ATC lubrication
-
Max Cutting Speed:
-
35000mm/min
Products Description
Product Details
Product Paramenters
|
Size
|
Working area
|
1300(X)x2500(Y)x200(Z)mm
|
|
|
Table size
|
1500x3000mm
|
|
|
Z-axis clearance
|
200mm
|
|
Structure
|
XYZ guiding rails
|
Original Taiwan HIWIN linear square rails
|
|
|
Body
|
Heavy duty seamless steel structure
|
|
|
Weight
|
2000kg
|
|
Accuracy
|
Positional accuracy
|
±0.03/300mm
|
|
|
Repeatability
|
±0.03
|
|
Spindle motor
|
Power
|
4PCS 6KW air cooling spindle
|
|
|
NO. of revolution
|
18000rpm
|
|
|
Motor
|
Original Taiwan DELTA servo motor and drives
|
|
Traverse system
|
MAX. Speed
|
30000mm/min
|
|
|
MAX. Cutting Speed
|
20000mm/min
|
|
Control parts
|
Controller
|
Original NC Studio 95A
|
|
|
Software
|
Type3/Artcam
|
|
|
Format
|
G code HPGL
|
|
Dust collector function
|
|
Yes
|
|
Lubrication system
|
|
ATC lubrication
|
|
Table
|
|
5 zones vacuum table plus T-slot
|
|
Vacuum pump
|
|
5.5 KW air vacuum pump
|
|
Tool diameter
|
|
3.175-12.7mm
|
|
Power supply
|
|
380V/50HZ, 3 phases
|
Product application
HOT Sale product
Rotary device 4 axis multi spindles cnc router machine
*Add rotary axis can 3d carving processing of cylindrical workpieces etc.
*Adopt original taiwan delta servo system, more faster.
*5 zones vacuum table with large suction air vacuum pump.
*Heavy-duty seamless welded structures design, with 2pcs air cooling spindles.
