Quick Details
-
Standard or Nonstandard:
-
Standard
-
Material:
-
Aluminium
-
Brand Name:
-
CHBG
-
Place of Origin:
-
Zhejiang, China
-
Service:
-
24 Hours Online
-
maximum inner dia:
-
42mm
-
minimum inner dia:
-
3mm
-
D range:
-
20-82mm
-
L range:
-
20-68mm
-
Certification:
-
CE ISO
-
customization:
-
keyway supported
-
Body Material:
-
Stainless Steel Aluminum Steel
-
MOQ:
-
1 Pcs
-
Application:
-
servo motor
Quick Details
-
Warranty:
-
3 years
-
Applicable Industries:
-
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company, Other
-
Structure:
-
Metal Bellows
-
Standard or Nonstandard:
-
Standard
-
Material:
-
Aluminium
-
Brand Name:
-
CHBG
-
Place of Origin:
-
Zhejiang, China
-
Service:
-
24 Hours Online
-
maximum inner dia:
-
42mm
-
minimum inner dia:
-
3mm
-
D range:
-
20-82mm
-
L range:
-
20-68mm
-
Certification:
-
CE ISO
-
customization:
-
keyway supported
-
Body Material:
-
Stainless Steel Aluminum Steel
-
MOQ:
-
1 Pcs
-
Application:
-
servo motor
|
Model
|
D (mm)
|
L (mm)
|
d1-d2 (mm)
|
hex screw
|
L1 (mm)
|
Fasten Torque (n.m)
|
|
LD1-B-D26L26
|
26
|
26
|
4-12
|
M3.0
|
11.4
|
1.4
|
|
LD1-B-D34L33
|
34
|
33
|
5-16
|
M4.0
|
14.5
|
5.1
|
|
LD1-B-D40L35
|
40
|
35
|
6-19
|
M4.0
|
14.5
|
5.1
|
|
LD1-B-D50L44
|
50
|
44
|
8-22
|
M4.0
|
19
|
5.1
|
|
Model
|
Weight (g)
|
Rated Torque (n.m)
|
Max speed (rpm)
|
Moment of Inertia (kg.m2)
|
Permissible Radial Deviation (degree)
|
Permissible Angular Deviation (degree)
|
|
LD1-B-D26L26
|
28
|
2
|
25000
|
1.1*10-6
|
0.02
|
1
|
|
LD1-B-D34L33
|
55
|
4.2
|
18000
|
4*10-6
|
0.02
|
1
|
|
LD1-B-D40L35
|
81
|
8
|
16000
|
1.6*10-5
|
0.02
|
1
|
|
LD1-B-D50L44
|
135
|
12
|
12000
|
2.0*10-5
|
0.02
|
1
|
|
How to get quotation
|
|
|
|
|
aperture D1
|
aperture D2
|
Coupling Diameter D
|
Coupling Length L
|
|
Sea port
|
tianjin/shanghai port
|
|
Supply Capacity
|
1000 units/month
|
|
Packing
|
Carton
|
Factory Strength
Our factory has the independent research and development ability, perfect quality-control system and high-quality workforce.
Coordinate Measuring Instrument
Product testing randomly, and offer test report.
Q:What kind of Couplings you can provide?
A: Check above specifications or email us to recommend motors based on your specification.
Q:Can you send me a price list?
A: Price varies according to annual quantity. If you send detailed requirements and annual quantity, you can get quick quotation.
Q:What's the lead period for regular order?
A: About 20 days if no stock. Period can be shorter or longer based on different model and quantity. Regular modes normally have stock.
Q: What's the MOQ? Can I just order few quantities?
A:Welcome to order for personal use or replacement. It’s no problem to send by international express delivery if regular mode has available stock.If MOQ, price and other terms are acceptable, we'd love to provide customized samples for your testing before official order.
Q: What's your payment term?
A:100% payment if quantity under 1000pcs. Above 1000pcs, 50% as deposit and 50% paid before shipment.
Q: How can I trust you to make sure my money is safe?
A: Order in trade assurance of Alibaba would be a good chose for you.
A: Check above specifications or email us to recommend motors based on your specification.
Q:Can you send me a price list?
A: Price varies according to annual quantity. If you send detailed requirements and annual quantity, you can get quick quotation.
Q:What's the lead period for regular order?
A: About 20 days if no stock. Period can be shorter or longer based on different model and quantity. Regular modes normally have stock.
Q: What's the MOQ? Can I just order few quantities?
A:Welcome to order for personal use or replacement. It’s no problem to send by international express delivery if regular mode has available stock.If MOQ, price and other terms are acceptable, we'd love to provide customized samples for your testing before official order.
Q: What's your payment term?
A:100% payment if quantity under 1000pcs. Above 1000pcs, 50% as deposit and 50% paid before shipment.
Q: How can I trust you to make sure my money is safe?
A: Order in trade assurance of Alibaba would be a good chose for you.
