Quick Details
-
Color:
-
Full Color
-
Panel Size:
-
240*120mm 320*160mm
-
Place of Origin:
-
Henan, China
-
Model Number:
-
FL2.5
-
HS Code:
-
8528591090
-
Resolution:
-
96*48 128*64
-
Pixel Conguration:
-
SMD
-
Viewing angle:
-
160/160degree
-
Color Depth(Bit):
-
16 bit
-
Software:
-
LED Studio
-
Brightness:
-
1100nits
-
MOQ:
-
1SQM
-
Cabinet size:
-
Customized
-
Product name:
-
Indoor P2.5 2.5Mm Soft Flexible Led Screen
-
Certificate:
-
CE ROHS FCC CCC ISO9001
Quick Details
-
Application:
-
Indoor
-
Type:
-
LED
-
Brand Name:
-
Canbest
-
Color:
-
Full Color
-
Panel Size:
-
240*120mm 320*160mm
-
Place of Origin:
-
Henan, China
-
Model Number:
-
FL2.5
-
HS Code:
-
8528591090
-
Resolution:
-
96*48 128*64
-
Pixel Conguration:
-
SMD
-
Viewing angle:
-
160/160degree
-
Color Depth(Bit):
-
16 bit
-
Software:
-
LED Studio
-
Brightness:
-
1100nits
-
MOQ:
-
1SQM
-
Cabinet size:
-
Customized
-
Product name:
-
Indoor P2.5 2.5Mm Soft Flexible Led Screen
-
Certificate:
-
CE ROHS FCC CCC ISO9001
Warranty
Products Description
Technical Parameter
|
Model Name
|
FL1.8
|
|
FL2
|
|
FL2.5
|
|
FL3
|
|
FL4
|
||||||||
|
Pixel Pitch
|
1.875 mm
|
|
2 mm
|
|
2.5 mm
|
|
3.076 mm
|
|
4 mm
|
||||||||
|
Module Size (W*H)
|
240*120 mm
|
320*160 mm
|
240*120 mm
|
320*160 mm
|
240*120 mm
|
320*160 mm
|
240*120 mm
|
320*160 mm
|
240*120 mm
|
||||||||
|
Module Resolution
|
128*64 dots
|
172*86 dots
|
120*60 dots
|
160*80 dots
|
96*48 dots
|
128*64 dots
|
80*40 dots
|
104*52 dots
|
60*30 dots
|
||||||||
|
Module Material
|
Silicone
|
Silicone
|
Silicone
|
Silicone
|
Silicone
|
Silicone
|
Silicone
|
Silicone
|
Silicone
|
||||||||
|
Module Net Weight
|
170 g
|
300 g
|
170 g
|
300 g
|
170 g
|
300 g
|
170 g
|
300 g
|
170 g
|
||||||||
|
LED Lamp Beads
|
SMD1515
|
SMD1212
|
SMD1515
|
SMD1515
|
SMD1515
|
SMD1515
|
SMD1515
|
SMD1515
|
SMD1515
|
||||||||
|
Brightness
|
700-900 cd/m²
|
|
|
|
|
|
|
|
|
||||||||
|
Refresh Rate
|
≥3840 Hz
|
|
|
|
|
|
|
|
|
||||||||
|
Driving Mode
|
1/32
|
1/43
|
1/32
|
1/40
|
1/24
|
1/32
|
1/20
|
1/26
|
1/16
|
||||||||
|
Color Depth
|
14 bit
|
|
|
|
|
|
|
|
|
||||||||
|
Viewing Angle
|
160°(H) / 160°(V)
|
|
|
|
|
|
|
|
|
||||||||
|
Input Voltage
|
AC110V~240V±5%
|
|
|
|
|
|
|
|
|
||||||||
|
Max. Power Consumption
|
700 W/㎡
|
700 W/㎡
|
700 W/㎡
|
700 W/㎡
|
700 W/㎡
|
700 W/㎡
|
700 W/㎡
|
700 W/㎡
|
600 W/㎡
|
||||||||
|
Ave. Power Consumption
|
215 W/㎡
|
215 W/㎡
|
215 W/㎡
|
215 W/㎡
|
215 W/㎡
|
215 W/㎡
|
215 W/㎡
|
215 W/㎡
|
215 W/㎡
|
||||||||
|
Working Life
|
≥100,000 h
|
|
|
|
|
|
|
|
|
||||||||
|
Protection Grade
|
IP20
|
|
|
|
|
|
|
|
|
||||||||
|
Maintenance
|
Front and Rear
|
|
|
|
|
|
|
|
|
||||||||
