Quick Details
-
Size:
-
customized
-
Place of Origin:
-
Shandong, China
-
Axle:
-
13/16 Ton
-
Tire:
-
11.00r20 12r22.5 315 385
-
King pin:
-
2"(50mm)or3.5"(90mm) JOST
-
Suspension System:
-
Mechanical Spring + Air Suspension System
-
Color:
-
Custom's Requirement
-
Main Beam:
-
T700/Q345 Steel
-
Tire Brand:
-
Triangle/double coin/Bridgestone
-
Condition:
-
Brand-new
-
Landing Gear:
-
JOST Brand Two-speed
-
Axle Brand:
-
BPW FUWA
Quick Details
-
Type:
-
Semi-Trailer
-
Max Payload:
-
>30000 kg
-
Brand Name:
-
GJ
-
Size:
-
customized
-
Place of Origin:
-
Shandong, China
-
Axle:
-
13/16 Ton
-
Tire:
-
11.00r20 12r22.5 315 385
-
King pin:
-
2"(50mm)or3.5"(90mm) JOST
-
Suspension System:
-
Mechanical Spring + Air Suspension System
-
Color:
-
Custom's Requirement
-
Main Beam:
-
T700/Q345 Steel
-
Tire Brand:
-
Triangle/double coin/Bridgestone
-
Condition:
-
Brand-new
-
Landing Gear:
-
JOST Brand Two-speed
-
Axle Brand:
-
BPW FUWA
We are the top one professional trailer manufacturer, and truck supplier in China.
We can give you better product and favorable price.
Product Paramenters
|
Specification
|
|
|
|
|||
|
|
20FT
|
40FT
|
53FT
|
|||
|
Dimension
|
6.1m×2.5m×1.55m
|
12.5m×2.5m×1.55m
|
16.2m×2.5m×1.55m
|
|||
|
Payload
|
40T
|
50T
|
60T
|
|||
|
Tare weight
|
About 4.5T
|
About 7T
|
About 8T
|
|||
|
Twist lock
|
4uints
|
12uints
|
12uints
|
|||
|
Axle
|
2 axles
|
2 axles/3 axles/4 axles
|
3 axles/4 axles
|
|||
|
Chassis
|
|
|
|
|||
|
Main beam
|
Heavy duty and extra durability designed I beam; Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes.
|
|
|
|||
|
Frame Beam
|
Top Flange 14mm,width 140mm; Middle Flange 8mm; Bottom Flange 16mm,width 140mm, main beam height 480mm
|
|
|
|||
|
Axle
|
13ton Fuwa,BPW, etc.
|
|
|
|||
|
Landing Gear
|
28T lifting capacity with two speed
|
|
|
|||
|
King Pin
|
2.00 or 3.5 inch bolt-in king pin ;Optional brand:JOST
|
|
|
|||
|
Suspension
|
Mechanical suspension reinforced type
|
|
|
|||
|
Leaf Spring
|
90mm(W)*13mm(T)*10 Layer
|
|
|
|||
|
Pneumatic Braking System
|
Dual line pneumatic brake system,T30 air chamber ,40L air tanks, Emergency relay valve
|
|
|
|||
|
Rim
|
9.0-20*12 pcs
|
|
|
|||
|
Tire
|
12R22.5*12 pcs
|
|
|
|||
|
Accessories
|
One standard tool box
|
|
|
|||
|
Spare tire rack
|
One
|
|
|
|||
|
Electrical system
|
24 volt electrical system.7 pin electrical connector. Parking stop, reverse, number plate and indicator lights. rear lights
conform to European standard, rear front and side reflectors |
|
|
|||
|
Painting
|
Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
|
|
|
|||
