Name:
Bitzer
Brand:
Germany brand
The compressor is the only engine of the refrigeration system,
it's just as the heart for a human being,
so the quality of compressor enfluence the refrigeration effect. Bitzer brand is good quality one, and widely used all over the world.
- Product Details
- {{item.text}}
Quick Details
-
Ice storage capacity:
-
2.5kg
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Kingwell
-
Dimension(L*W*H):
-
1660mm(L)*950mm(W)*2120mm(H)
-
Weight:
-
1500 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Compressor:
-
Bitzer/Refcomp
-
Cooling way:
-
Air/Water Cooling
-
Material of mainframe:
-
304# Stainless Steel
-
Electrical Components:
-
LG(LS)
-
Control system:
-
Siemens PLC Program Control System
-
Tube ice diameter:
-
28~40mm
-
Compressor Power:
-
14 HP
-
Material:
-
Stainless Steel 304
-
Name:
-
Tube ice machine
Quick Details
-
Ice Shape:
-
tube ice
-
Voltage:
-
380v, 50hz, 3p/220v, 60hz, 3p
-
Power:
-
10.5KW
-
Ice storage capacity:
-
2.5kg
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Kingwell
-
Dimension(L*W*H):
-
1660mm(L)*950mm(W)*2120mm(H)
-
Weight:
-
1500 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Compressor:
-
Bitzer/Refcomp
-
Cooling way:
-
Air/Water Cooling
-
Material of mainframe:
-
304# Stainless Steel
-
Electrical Components:
-
LG(LS)
-
Control system:
-
Siemens PLC Program Control System
-
Tube ice diameter:
-
28~40mm
-
Compressor Power:
-
14 HP
-
Material:
-
Stainless Steel 304
-
Name:
-
Tube ice machine
Tube Ice Making Machine 3 Ton 5 Ton Sale Hot in Philippines
With Factory Direct Sell Price
Product Description
This product is cooled by water, so it has 2 parts: tube ice maker part and cooling tower, they are connecting by water pump and water pipes.
Main Features
1) Food-grade : we use the food-grade material to manufacture the machine, all the parts which are contacting water and ice are stainless steel 304.
2) Easy and safe operation : we use PLC micro-computer program and touch screen to control the machine, so it is easy to operate the machine; all the wires are well-protected, and the Freon gas is a kind of stable and safe gas, so it is safe to operate it.
3) Simple and economic packaging system : we can design a storage bin with a screw conveyor on its bottom, so you can take the ice out and pack them into plastic bags easily.
4) Power consumption: about 70~80KW*H to make 1 ton ice.
Water consumption: about 1.05 tons water to make 1 ton ice.
Black Cotton Heat Preservation Cover
SUS304 Insulation Cover
Detailed Images
Compressor
PLC Program controller
Name:
SIEMENS
Brand:
Germany brand
This PLC is just
as the brain for a human being
, it controls all the electrical parts of the machine, to guide all part when to work and stop, so the
whole ice making and ice falling process are totally automatic.
SiEMENS brand is also widely used over the world.
Electrical box
Switch Brand: LS (South Korea)
PLC Brand: Simens (Germany)
Contactor Brand: LS (South Korea)
Overload Brand: LS (South Korea)
Touch Screen
Brand:
Weicon
Orginal:
Taiwan
This touch screen can adjust some datas and ice thickness,
all the working states and working histories can be seen clearly on the screen,
so when there is some error of the machine, you can show the video and picture to the factory, problems can be judged quickly
.
Crystal Tube Ice
We have different tube ice for option, the inner hole can be adjusted 5~10mm
|
Outside Diameter of tube ice
|
Standard length
|
Freezing time
|
|
|
|
16mm
|
25mm
|
14 minutes
|
|
|
|
22mm
|
30mm
|
16 minutes
|
|
|
|
28mm
|
35mm
|
18 minutes
|
|
|
|
34mm
|
45mm
|
22 minutes
|
|
|
|
40mm
|
55mm
|
25 minutes
|
|
|
