Quick Details
-
Warranty:
-
25 YEARS
-
Brand Name:
-
Bluesun
-
Model Number:
-
BSM425G12-54HPH
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1722*1134*30mm
-
Frame:
-
Silver
-
Max. Power:
-
425W
-
Application:
-
solar power system
-
Packing:
-
pallets or wooden box
-
Solar cell:
-
Monocrystalline Silicon Cells
-
OEM Order:
-
Customized Solar Panel Aavilable
-
Connector:
-
Compatible Connector
-
Feature:
-
Energy Conservation System
-
Product name:
-
Photovoltaic Solar Panels
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell
-
Panel Efficiency:
-
21.3%
-
Warranty:
-
25 YEARS
-
Brand Name:
-
Bluesun
-
Model Number:
-
BSM425G12-54HPH
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1722*1134*30mm
-
Frame:
-
Silver
-
Max. Power:
-
425W
-
Application:
-
solar power system
-
Packing:
-
pallets or wooden box
-
Solar cell:
-
Monocrystalline Silicon Cells
-
OEM Order:
-
Customized Solar Panel Aavilable
-
Connector:
-
Compatible Connector
-
Feature:
-
Energy Conservation System
-
Product name:
-
Photovoltaic Solar Panels
Product Description
|
SPECIFICATIONS
|
|
|
|
|
|
|
|
|
||||||||
|
Module Type
|
BSM410G12-54HPH
|
|
BSM415G12-54HPH
|
|
BSM420G12-54HPH
|
|
BSM425G12-54HPH
|
|
||||||||
|
|
STC
|
NMOT
|
STC
|
NMOT
|
STC
|
NMOT
|
STC
|
NMOT
|
||||||||
|
Maximum Power (Pmax/W)
|
410
|
306
|
415
|
310
|
420
|
314
|
425
|
318
|
||||||||
|
Operating Voltage (Vmpp/V)
|
31.43
|
29.3
|
31.64
|
29.6
|
31.83
|
29.8
|
32.03
|
30.0
|
||||||||
|
Operating Current(Impp/A)
|
13.05
|
10.42
|
13.13
|
10.48
|
13.21
|
10.54
|
13.29
|
10.60
|
||||||||
|
Open-Circuit Voltage (Voc/V)
|
37.50
|
35.30
|
37.75
|
35.50
|
38.00
|
35.70
|
38.25
|
35.90
|
||||||||
|
Short-Circuit Current (Isc/A)
|
13.94
|
11.24
|
14.02
|
11.30
|
14.10
|
11.36
|
14.18
|
11.42
|
||||||||
|
Module Efficiency (%)
|
21
|
|
21.3
|
|
21.5
|
|
21.7
|
|
||||||||
|
STC: Irradiance 1000W/㎡ . Cell Temperature 25℃, Air Mass AM1.5 NMOT: Irradiance at 800Wm . Ambient Temperature 2(TC. Air Mass AM1.5, Wind Speed 1m/s
|
|
|
|
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|||||||||
Packing & Delivery
Certifications
Our Project
Payment
|
Payment Term |
T/T |
EXW
|
30% T/T in advance, paid the balance before shipment |
||
|
|
|
FOB
|
|
||
|
|
|
CNF
|
30% T/T in advance, paid the balance against copy of B/L |
||
|
|
|
CIF
|
|
||
|
|
L/C
|
L/C amount above 50,000 usd, we can accept L/C at sight
|
|
||
|
|
West Union
|
Amount lower than 5000usd
|
|
||
|
Delivery Time
|
7~10days after receiving payment for one container
|
|
|
||
