Quick Details
-
Mounting Type:
-
recessed mounted light post
-
Description:
-
low consumption 1.5VA, -
-
Manufacturing Date Code:
-
-
-
Model Number:
-
LT210A
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
LEAD TOP
-
Theory:
-
-, Optical sensor
-
Output:
-
-, Switching Transducer
-
Rated Voltage:
-
240V
-
Rated Load:
-
2000W/1800VA
-
Frequency:
-
50-60 Hz
-
ON/OFF Ratio:
-
1:5
-
Operating Temperature:
-
-40℃ to +70℃
-
Light Sensor:
-
Cadmium Sulfide (Cds) Cell
-
Fail Mode:
-
Fail On
-
Standard:
-
ANSI C136.24&UL773A
Quick Details
-
Use:
-
Lighting Sensor
-
Series:
-
button controller
-
Features:
-
automatic control street light on-ff
-
Mounting Type:
-
recessed mounted light post
-
Description:
-
low consumption 1.5VA, -
-
Manufacturing Date Code:
-
-
-
Model Number:
-
LT210A
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
LEAD TOP
-
Theory:
-
-, Optical sensor
-
Output:
-
-, Switching Transducer
-
Rated Voltage:
-
240V
-
Rated Load:
-
2000W/1800VA
-
Frequency:
-
50-60 Hz
-
ON/OFF Ratio:
-
1:5
-
Operating Temperature:
-
-40℃ to +70℃
-
Light Sensor:
-
Cadmium Sulfide (Cds) Cell
-
Fail Mode:
-
Fail On
-
Standard:
-
ANSI C136.24&UL773A
PRODUCT DESCRIPTION
Technical Specification:
Standard: ANSI C136.24&UL773A
Rated Volts: 240V
Frequency: 50-60 Hz
Rated Volts: 240V
Frequency: 50-60 Hz
Rated Load: 2000W/1800VA
Turn-On Light Levels:10-16 Lux
Turn-Off Light Levels:65 Lux
ON/OFF Ratio: 1:5
Time Delay: 30-180 Seconds
Fail Mode: ON
Operating Temperature: -40℃ to +70℃
Switch: >5000 ON/OFF Operations at Rated Load
Power Consumption: ≤ 0.7 watts at 120VAC
Light Sensor: CDS
Housing: Anti-UV Impact Resistance Polycarbonate (PC)
Turn-On Light Levels:10-16 Lux
Turn-Off Light Levels:65 Lux
ON/OFF Ratio: 1:5
Time Delay: 30-180 Seconds
Fail Mode: ON
Operating Temperature: -40℃ to +70℃
Switch: >5000 ON/OFF Operations at Rated Load
Power Consumption: ≤ 0.7 watts at 120VAC
Light Sensor: CDS
Housing: Anti-UV Impact Resistance Polycarbonate (PC)
|
Model
|
Rated Volts
|
Rating Tungsten
|
Rating Ballast
|
Rating LED
|
|
LT210A1
|
120V
|
1800W
|
1800VA
|
5A E-Ballast
|
|
LT210A2
|
240V
|
2000W
|
2000W
|
5A E-Ballast
|
|
LT210A3
|
208V-277V
|
2000W
|
2000W
|
5A E-Ballast
|
|
LT210LA1
|
120V
|
1000W
|
1200VA
|
2A E-Ballast
|
|
LT210LA2
|
240V
|
1000W
|
1200VA
|
2A E-Ballast
|
|
LT210LA3
|
208V-277V
|
1000W
|
1200VA
|
2A E-Ballast
|
