Quick Details
-
Brand Name:
-
Haiyu
-
Voltage:
-
380v,415v,220v
-
Power:
-
3.8kw
-
Dimension(L*W*H):
-
2.1x0.85x0.65
-
Weight:
-
900 kg
-
Features:
-
Prestressed
-
Warranty:
-
12 MONTHS
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Prestressed:
-
steel wire inside
-
forming speed:
-
1.6m/min
-
Certification:
-
CE,ISO
Quick Details
-
Application:
-
fence wall panel
-
Production Capacity:
-
1.4m/min
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Haiyu
-
Voltage:
-
380v,415v,220v
-
Power:
-
3.8kw
-
Dimension(L*W*H):
-
2.1x0.85x0.65
-
Weight:
-
900 kg
-
Features:
-
Prestressed
-
Warranty:
-
12 MONTHS
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Prestressed:
-
steel wire inside
-
forming speed:
-
1.6m/min
-
Certification:
-
CE,ISO
concrete fence making machine/precast concrete fence panels
1.The concrete product produced by HQJ machine can be used as internal walls, external walls,roof of houses with the materials of cement, sand and aggregate.
2.HQJ panel machine is a movable producing panel machine which need simple platform to move during producing.
3.steel wire of 2mm diameters are put inside the panel in advance before producing
4.Machine original materials is of high and good quality,special and professional productive technogloy to ensure you the best machine in the industry.
Main specifications:
|
Model(mm) |
HQJ80X600 |
HQJ90X600 |
HQJ100X600 |
HQJ120X600 |
HQJ200X600 |
HQJ240X280X2 |
|
Panel width |
595±2 |
595±2 |
595±2 |
595±2 |
595±2 |
280±2 |
|
thickness(mm) |
78±1 |
88±1 |
88±1 |
118±1 |
198±1 |
238±1 |
|
No of hole including diameter (mm) |
8Xφ43 |
7Xφ58 |
7Xφ62 |
5Xφ80 |
3Xφ145 |
1Xφ160 |
|
forming speed(mm/min) |
1600 |
1600 |
1600 |
1600 |
1600 |
1600 |
|
Main power(KW) |
4 |
5.5 |
5.5 |
5.5 |
7.5 |
7.5 |
|
vibration power(KW) |
0.8 |
0.8 |
0.8 |
0.8 |
3 |
3 |
|
machine dimentions(mm) |
2500X950X750 |
2500X950X700 |
2500X950X750 |
2550X950X750 |
2650X1000X850 |
2650X1000X900 |
|
machine weight(kg) |
1010 |
1010 |
1035 |
1650 |
1680 |
1740 |
Production:
Finished products :
Used as boundary wall with H beam
