- Product Details
- {{item.text}}
Quick Details
-
Color:
-
68.7billion
-
Panel Size:
-
500x1000mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
DDW-IF MI
-
Pixel Pitch:
-
6.25mm, 6.25mm
-
Brightness:
-
900-3000 cd/m²
-
pixel density:
-
12800dot/m²
-
Contrast Ratio:
-
>3000:1
-
Color Depth:
-
1R1G1B
-
Lifespan (hours):
-
100,000hours
-
IP Rating:
-
IP54/IP45
-
HS Code:
-
8528591090
-
Resolution:
-
80x160dots/cabinet
-
View Angle（H/V）:
-
160°/160°
-
Module size:
-
250x250mm
-
Tube chip color:
-
Fulll Color
-
Usage:
-
Indoor led display
-
Operating Voltage:
-
100-240V AC 50-60Hz
-
Refresh Rate:
-
3840Hz
-
Cabinet Material:
-
Iron
-
Cabinet Weight(Kg/Cabinet):
-
23
-
Max Load-Bearing:
-
2200kg
Quick Details
-
Application:
-
Indoor
-
Type:
-
LED
-
Brand Name:
-
DDW Or Customized
-
Color:
-
68.7billion
-
Panel Size:
-
500x1000mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
DDW-IF MI
-
Pixel Pitch:
-
6.25mm, 6.25mm
-
Brightness:
-
900-3000 cd/m²
-
pixel density:
-
12800dot/m²
-
Contrast Ratio:
-
>3000:1
-
Color Depth:
-
1R1G1B
-
Lifespan (hours):
-
100,000hours
-
IP Rating:
-
IP54/IP45
-
HS Code:
-
8528591090
-
Resolution:
-
80x160dots/cabinet
-
View Angle（H/V）:
-
160°/160°
-
Module size:
-
250x250mm
-
Tube chip color:
-
Fulll Color
-
Usage:
-
Indoor led display
-
Operating Voltage:
-
100-240V AC 50-60Hz
-
Refresh Rate:
-
3840Hz
-
Cabinet Material:
-
Iron
-
Cabinet Weight(Kg/Cabinet):
-
23
-
Max Load-Bearing:
-
2200kg
Discover Your Right Application , Make Your Business Possible !
Common warranty in LED field is 2 years, ours is 3 years Longer warranty periods, better after-sale services, worry-free user experience
Project Case
LED displays have been exported to many countries and rigions in the World, and we are highly praised by our customers.
Products Description
Specifications
|
Pixel Pitch (mm)
|
2.5
|
2.6
|
2.976
|
3.91
|
4.81
|
5.2
|
6.25
|
||||||
|
LED Configuration
|
SMD1415
|
SMD1415
|
SMD1415
|
SMD1921
|
SMD1921
|
SMD1921
|
SMD1921
|
||||||
|
Module Resolution
|
100 x 100 pixels
|
96 x 96 pixels
|
84 x 84 pixels
|
64 x 64 pixels
|
52 x 52 pixels
|
48 x 48 pixels
|
40x 40 pixels
|
||||||
|
Module Dimensions(W x H x D)(mm)
|
250 x 250 x 18
|
|
|
|
|
|
|
||||||
|
Cabinet Resolution
|
200 x 200 pixels
|
192 x 192 pixels
|
168 x 336 pixels
|
128 x 256 pixels
|
104 x 208 pixels
|
96 x 192 pixels
|
80 x 160 pixels
|
||||||
|
Cabinet Dimensions(W x H x D)(mm)
|
500 x1,000 x 60
|
|
|
|
|
|
|
||||||
|
Contrast Ratio
|
>3,000:1
|
|
|
|
|
|
|
||||||
|
Brightness (cd/㎡)
|
900-1800
|
900-1800
|
900-1800
|
900-1800
|
900-3000
|
900-3000
|
900-3000
|
||||||
|
Max./Avg. Power(W)
|
400 / 200
|
|
|
|
|
|
|
||||||
|
Viewing Angle
|
160°/160°
|
|
|
|
|
|
|
||||||
|
Operating Voltage
|
100-240V AC 50-60Hz
|
|
|
|
|
|
|
||||||
|
Refresh Rate
|
3840Hz
|
|
|
|
|
|
|
||||||
|
IP Rating
|
IP54/IP45
|
|
|
|
|
|
|
||||||
|
Cabinet Weight(Kg)
|
23
|
|
|
|
|
|
|
||||||
|
Cabinet Material
|
Iron
|
|
|
|
|
|
|
||||||
|
Max Load-Bearing
|
2200 Kg
|
|
|
|
|
|
|
||||||
