Quick Details
-
Waterproof:
-
IP66 Water-proof
-
Product name:
-
Tuya solar camera
-
Storage:
-
Cloud Storage/TF Card( Max 128GB)
-
APP:
-
Tuya/i-Cam+
-
IR Distance:
-
30 Meters
-
Power Supply:
-
Solar +18650 Battery*6
-
Lens:
-
4mm Prime lens
-
Minimum:
-
1lux
-
Special Features:
-
Human Motion Tracking
-
Solar panel:
-
8W
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
TUYXCIE
-
Model Number:
-
Q5B
-
Waterproof:
-
IP66 Water-proof
-
Product name:
-
Tuya solar camera
-
Storage:
-
Cloud Storage/TF Card( Max 128GB)
-
APP:
-
Tuya/i-Cam+
-
IR Distance:
-
30 Meters
-
Power Supply:
-
Solar +18650 Battery*6
-
Lens:
-
4mm Prime lens
-
Minimum:
-
1lux
-
Special Features:
-
Human Motion Tracking
-
Solar panel:
-
8W
Product Paramenters
|
Video
|
Master sensor
|
1080P
|
lngenic T31ZL+2063
|
|
|
|||
|
|
|
1920P
|
lngenic T31ZX+4653
|
|
|
|||
|
|
Video resolution
|
Main stream: 1920x1080@15fps, Sub stream: 640x360@15fps
|
|
|
|
|||
|
|
Video recording
|
Compression format
|
H.265
|
|
|
|||
|
|
|
Video format
|
MP4
|
|
|
|||
|
|
lens
|
4mm F2.0 lens, Low lux., wide view angle: 120 degrees. 4X digital zoom
|
|
|
|
|||
|
|
night vision
|
6pcs array infrared LEDs, night vision distance 30m. Full-colorful day/night
|
|
|
|
|||
|
Audio
|
Audio compression
|
G.726/AAC. Audio code rate: 8Kbps, 16bit
|
|
|
|
|||
|
|
Audio input/output
|
Built-in MIC and Speakers, support two way audio
|
|
|
|
|||
|
|
PIR motion detection
|
Support max 12 meters PIR detection range.
|
|
|
|
|||
|
|
Alarm linkage
|
Alarm record videos to Micro SD card;Alarm mobile phone message push
|
|
|
|
|||
|
Video storage
|
Memory card
|
Support up to 128G micro SD card. Support cloud storage
|
|
|
|
|||
|
|
Recording mode
|
PIR alarm recording.
|
|
|
|
|||
|
|
Video playback
|
Support App remote play and download the video
|
|
|
|
|||
|
|
solar panel
|
6W monocrystalline silicon solar panel
|
|
|
|
|||
|
|
battery
|
Built-in 3 pcs battery
|
|
|
|
|||
|
|
Working mode
|
Low power working mode, can work for 5 months without power supply
|
|
|
|
|||
|
|
Wake-up mode
|
PIR alarm wake up, remote manual wake up
|
|
|
|
|||
|
|
Dormant state
|
When alarm end or remote connection disconnected.
|
|
|
|
|||
|
|
Power consumption
|
Sleeping stand-by power: 0.03W; Working: 1.3W@days/3W@night
|
|
|
|
|||
Specification:
Wireless WiFi Frequency:
2.4 GHz, IEEE802.11b, 802.11g, 802.11n Draft
Main control sensor:
1080P, main control+lngenic T31ZL+2063
Video resolution:
Main stream code: 1920x1080@15fps, Sub stream code: 640x360@15fps
Battery:
Built-in 3 18650 batteries, the total capacity is
up to 9600mAh
Sleep state:
when the alarm ends or the remote connection is disconnected
Rotation angle:
horizontal translation: 0°～355°, vertical tilt: 0°～120°
Rotation speed:
Horizontal speed: 10°～30°/S; Vertical speed: 8°～25°/S
Power input:
DC5V 2A
Use environment:
environment -20℃~+60℃(-4℉~+140℉), humidity 10%~80%
Shell material:
ABS fireproof plastic material, anti-vandal, waterproof grade IP65
Power cord:
Type-c interface, extension cord 3 meters
Product size:
22.3cm×17cm×23cm (length×width×height)
How to set 4g camera online?
1.After you receive camera, please charge the solar panel 10 hours use
5V2A
Charger.
2.The 4G sim card should have traffic data.
3.How to insert sim card? Power off the solar camera, insert the 4g sim card, power on the solar camera then reset the security camera.then wait 1~3 mins, let camera search the 4g sim card data, then the camera would show blue led always on.(if red light on or blue and red light flashing,please check your sim card data.)
2.The 4G sim card should have traffic data.
3.How to insert sim card? Power off the solar camera, insert the 4g sim card, power on the solar camera then reset the security camera.then wait 1~3 mins, let camera search the 4g sim card data, then the camera would show blue led always on.(if red light on or blue and red light flashing,please check your sim card data.)
4G version:
This wifi battery outdoor security camera does NOT support NVR/DVR access.
1.
Does not support connection to home WiFi.
No network LAN cable required! No need to set up wifi! No need to connect household wires and cables!
You can plug in a 4G SIM card and receive data over the Internet. It cannot connect to wifi network, please pay attention when buying.
2.camera is mainly used in the environment without internet, can not supply power, but has SIM card mobile signal and sunny.You need to put the SIM card in the camera and connect to the internet through the SIM card.
3.Solar camera does not support router internet connection. 4G network camera supports Cloud FTP storage!
4.It supports mobile applications , iOS and Android systems. view anytime, anywhere. Supports two-way audio.
2.camera is mainly used in the environment without internet, can not supply power, but has SIM card mobile signal and sunny.You need to put the SIM card in the camera and connect to the internet through the SIM card.
3.Solar camera does not support router internet connection. 4G network camera supports Cloud FTP storage!
4.It supports mobile applications , iOS and Android systems. view anytime, anywhere. Supports two-way audio.
4G Versions Are Available In Different Countries And Regions
Our equipment in different countries will be adapted to the 4G version according to each country. The BAND specifications corresponding to each version is as follows:
WiFi Version:
1.This wifi version only supports 2.Ghz wifi networks, not 4G SIM cards.
usually need to use wifi network to connect the device.
2. This product requires 4 21700 batteries. Shipped with battery.
3.No need to connect household wires and cables! Supports wifi, no LAN cable required.
4.Using solar energy, energy saving and environmental protection, you can install it anywhere (requires Wifi network), such as gardens, farms, streets.
5.Uninterrupted solar panel work The rechargeable battery IP wifi camera can work continuously without the need to remove the battery to charge through an external solar panel
Packing Included:
1* Solar Camera(included battery or not)
1* Solar Panel
1* 3m extension cable
1* Set of Screw
1* User Manual
1* Solar Panel
1* 3m extension cable
1* Set of Screw
1* User Manual
Warm Tips:
1. Camera need work with 2.4Ghz WiFi (no support 5G network).
2. Your wifi name & password must be English or Arabic numerals..
3.Camera can not support programmed with computers or NVR systems.
2. Your wifi name & password must be English or Arabic numerals..
3.Camera can not support programmed with computers or NVR systems.
