Quick Details
-
Place of Origin:
-
China
-
Dimension(Long * Breadth * High):
-
8120*2800*3450mm
-
Machine Weight:
-
17200 kg
-
Bucket capacity:
-
3.0 m³, 3.0 m³
-
Marketing Type:
-
New Product
-
Rated Payload:
-
5000kg
-
Rated Power:
-
158/162KW
Quick Details
-
Engine Brand:
-
top brand
-
Power:
-
158/162KW
-
Brand Name:
-
top brand
-
Place of Origin:
-
China
-
Dimension(Long * Breadth * High):
-
8120*2800*3450mm
-
Machine Weight:
-
17200 kg
-
Bucket capacity:
-
3.0 m³, 3.0 m³
-
Marketing Type:
-
New Product
-
Rated Payload:
-
5000kg
-
Rated Power:
-
158/162KW
Contact
Sales Manager
Yolanda Wang
Maxizm Construction Machinery (Qingdao) Co., Ltd.
Yolanda Wang
Maxizm Construction Machinery (Qingdao) Co., Ltd.
Email:
yolanda@maxizm.com
Wechat/ Mobile/Whatsapp: +86 18753855378
Wechat/ Mobile/Whatsapp: +86 18753855378
Products Description
1.Equipped with imported original cummins electronic control diesel engine, turbocharging and air-to-air inter cooler to meet EU III emission standards.
2.Imported Germany's automatic transmission to achieve four forward and three reverse gear selection.
3.Germany's wet driving axle with limited slip differential for adhesion, stability and reliability.
4.Rexroth pilot valve and working valve, Japan's Kawasaki conversion valve, American PARKER vane pump and hydraulic hoses.
5.FOPS/ROPS for more reliable operation safety.
2.Imported Germany's automatic transmission to achieve four forward and three reverse gear selection.
3.Germany's wet driving axle with limited slip differential for adhesion, stability and reliability.
4.Rexroth pilot valve and working valve, Japan's Kawasaki conversion valve, American PARKER vane pump and hydraulic hoses.
5.FOPS/ROPS for more reliable operation safety.
Product Paramenters
|
Model
|
957S
|
|
Length×Width×Height(mm)
|
8120×2800×3450
|
|
Rated load (Kg)
|
5000
|
|
Rated bucket capacity(m3)
|
3.0
|
|
Operating weight(Kg)
|
17200
|
|
Diesel engine
|
Cumins 6LTAA 9.3/Shang-Chai SC11CB220G2B1
|
|
Rated output(KW)
|
158/162
|
|
Transmission case
|
Z/F
|
|
Gear positions
|
4 forward gear, 3 reverse gear
|
|
Max. drawing force(KN)
|
170
|
|
Max. dump clearance(mm)
|
3136
|
|
Dump reach (mm)
|
1121
|
|
Wheel base(mm)
|
3300
|
|
Total cycle time (s)
|
11
|
