Quick Details
-
Weight (KG):
-
176 KG
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
HT
-
Voltage:
-
220V
-
Dimension(L*W*H):
-
1470(H)*830(W)*925(D)mm
-
Power (kW):
-
0.75 kW
-
Marketing Type:
-
Hot sale in 2020
-
Core Components:
-
main vibrator, container press cover, microcomputer
-
Case weight:
-
176KG
-
Number and capacity of canister:
-
16 canisters * 2.3L
-
Canister material:
-
PP plastic or 304 stainless steel
-
Piston pumps body material:
-
Stainless steel
-
Max. paint container size:
-
320*380mm
-
Power source:
-
220V+10% 50HZ
-
Max. power consumption:
-
100w(does not include computer equipments)
-
Machine size:
-
1470 (H) *830 (w) *925 (D) mm
-
Shipping size:
-
1495 (H) *880 (w) *975 (D) mm
-
Shipping weight:
-
240kg
Quick Details
-
Barrel Volume (L):
-
20
-
Max. Loading Volume (L):
-
36.8 L
-
Max. Loading Capacity:
-
20
-
Weight (KG):
-
176 KG
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
HT
-
Voltage:
-
220V
-
Dimension(L*W*H):
-
1470(H)*830(W)*925(D)mm
-
Power (kW):
-
0.75 kW
-
Marketing Type:
-
Hot sale in 2020
-
Core Components:
-
main vibrator, container press cover, microcomputer
-
Case weight:
-
176KG
-
Number and capacity of canister:
-
16 canisters * 2.3L
-
Canister material:
-
PP plastic or 304 stainless steel
-
Piston pumps body material:
-
Stainless steel
-
Max. paint container size:
-
320*380mm
-
Power source:
-
220V+10% 50HZ
-
Max. power consumption:
-
100w(does not include computer equipments)
-
Machine size:
-
1470 (H) *830 (w) *925 (D) mm
-
Shipping size:
-
1495 (H) *880 (w) *975 (D) mm
-
Shipping weight:
-
240kg
Function
1、The dispenser software is extremely flexible, is compatible with diferent tinting systems and can be easily interfaced with themajority of formula books and color matching software.
2、Usual operations as purging, dispensing, canister filing, colorant mixing etc. are easy and very quick to perform.
3、Operator errors are vitually eliminate using real-time dispensing control and an accurate error handing software.
4、Access to last dispensed formulas, saved recipes and client flies is unlimited.Formula information can be easily printed or storedfor future usage.
5、Level of colorants in each canister can be visualized and managed at a glance.
6、Both the automatic purging function and “"hermetic" nozzle caps assures clean and accurate dispensing all the time.
7、Full control on individual pumps and valves speed allows to perform accurate dispensing even with high viscosity colorants.
8、The base can lifter is controlled by different sensors to make the can positioning accurate and extremely safe for the operator.
9、The can sensor also avoids dispensing when the base can is not properly positioned.
|
Products name
|
HT-10A Automatic paint Dispenser
|
|
Case weight
|
176kg
|
|
Colorant mixing
|
Automatic (1 minutes to 12 hours waiting, 1 to 20 minutes mixing) or manually controlled.
|
|
Power source
|
220V+10% 50HZ
|
|
Min. accurate discharge
|
1/384 of fluid ounce or ml
|
|
Max. pump discharge
|
55ml or 2 fluid ounces per stroke
|
|
Machine size
|
1470 (H) x830 (w) x925 (D) mm
|
|
Packing size
|
1495 (H) x880 (w) x975 (D) mm
|
Q1: After-sales Service
A: 1 year warranty for all kinds of products
A: 1 year warranty for all kinds of products
Q2: When will make delivery ?
A: -Stock Order: 3-7days after receipt of the full payment
-OEM Order: 10-30days after receipt of the deposit.
A: -Stock Order: 3-7days after receipt of the full payment
-OEM Order: 10-30days after receipt of the deposit.
