Quick Details
-
Power (kW):
-
15
-
Range of Spindle Speed(r.p.m):
-
2000 - 4000 r.p.m
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
XINYOU
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
860*900*1900mm
-
Weight (KG):
-
760 KG
-
Product name:
-
flower herb grinder fine powder herb pulverizer hammer mill for spice
-
Machine Type:
-
Blade mill
-
Spare parts:
-
mesh screen
-
MOQ:
-
1 Set
-
Cooling system:
-
water cooler
-
Cleaning means:
-
Air Compressor
-
Motor brand:
-
Domestic Brand
-
Package:
-
Plywood Case+foam
Quick Details
-
Output (kg/h):
-
300 - 500 kg/h
-
Feeding Size (mm):
-
100 - 200 mm
-
Output Size (mesh):
-
20 - 120 mesh
-
Power (kW):
-
15
-
Range of Spindle Speed(r.p.m):
-
2000 - 4000 r.p.m
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
XINYOU
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
860*900*1900mm
-
Weight (KG):
-
760 KG
-
Product name:
-
flower herb grinder fine powder herb pulverizer hammer mill for spice
-
Machine Type:
-
Blade mill
-
Spare parts:
-
mesh screen
-
MOQ:
-
1 Set
-
Cooling system:
-
water cooler
-
Cleaning means:
-
Air Compressor
-
Motor brand:
-
Domestic Brand
-
Package:
-
Plywood Case+foam
Product Overview
WF series universal grinding machine
Product Application
This pin mill is widely used in Food, chemical and other industries.
There are different models for different requirement.
It has mesh screen inside of the grinding chamber, you can get the powder size by changing the screen size.
Easy to operate,clean and maintenance.
Main Features
1. This grinding machine is widely used in food, chemical and other industry.
2. For normal material, it can grind into 20-120 mesh.Customer can use different size of sieves to get the fineness they need.
3. This machine has different models, capacity from 20-1000 kg/h, customers can choose the right model according to their requirement.
4. The temperature during the crushing process is less than 40 ℃. For sensitive material, customer can choose water cooler or air cooler.
5. Stable quality of finished product with low consumption to save cost.
6. Simple structure, convenient cleaning and low noise.
7. The machine can be equipped with dust collector, no fine powder flying during the grinding process.
8. We can make the input hopper be magnetic to avoid metal damage if you need.
This pin mill is widely used in Food, chemical and other industries.
There are different models for different requirement.
It has mesh screen inside of the grinding chamber, you can get the powder size by changing the screen size.
Easy to operate,clean and maintenance.
Main Features
1. This grinding machine is widely used in food, chemical and other industry.
2. For normal material, it can grind into 20-120 mesh.Customer can use different size of sieves to get the fineness they need.
3. This machine has different models, capacity from 20-1000 kg/h, customers can choose the right model according to their requirement.
4. The temperature during the crushing process is less than 40 ℃. For sensitive material, customer can choose water cooler or air cooler.
5. Stable quality of finished product with low consumption to save cost.
6. Simple structure, convenient cleaning and low noise.
7. The machine can be equipped with dust collector, no fine powder flying during the grinding process.
8. We can make the input hopper be magnetic to avoid metal damage if you need.
|
Model
|
Input size
|
Output size
(mesh)
|
Capacity
(kg/h)
|
Grinding moor
|
Speed
|
Overall dimension
(mm)
|
Weight
|
|
WF-20B
|
<10mm
|
20-120
|
20-50
|
4kw
|
4500
|
500*650*1200
|
185kg
|
|
WF-30B
|
<10mm
|
20-120
|
50-150
|
5.5kw
|
3800
|
600*750*1350
|
210kg
|
|
WF-40B
|
<10mm
|
20-120
|
100-300
|
11kw
|
3400
|
700*850*1550
|
350kg
|
|
WF-60B
|
<10mm
|
20-120
|
300-500
|
22kw
|
2900
|
800*870*1780
|
500kg
|
|
WF-80B
|
<10mm
|
20-120
|
500-800
|
37kw
|
2000
|
900*900*1910
|
1000kg
|
|
WF-100B
|
<10mm
|
20-120
|
800-1000
|
55kw
|
1500
|
1400*1100*2800
|
2000kg
|
