automatic brick machines aac alc hebel panel block making plant cost Philippines
automatic brick machines aac alc hebel panel block making plant cost Philippines
automatic brick machines aac alc hebel panel block making plant cost Philippines
automatic brick machines aac alc hebel panel block making plant cost Philippines
automatic brick machines aac alc hebel panel block making plant cost Philippines
automatic brick machines aac alc hebel panel block making plant cost Philippines
automatic brick machines aac alc hebel panel block making plant cost Philippines
automatic brick machines aac alc hebel panel block making plant cost Philippines

automatic brick machines aac alc hebel panel block making plant cost Philippines

FOB Reference Price: Get Latest Price
≥2 Sets
US $600000
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Brick size:
600*200*100/150/200
Place of Origin:
Shandong, China
Brand Name:
weida
Voltage:
380/415/440V(customerized)
Dimension(L*W*H):
depends
Core Components:
Siemens standars
Weight (KG):
100000 kg
Capacity:
30000M3/year
Key Selling Points::
automatic
Pallet size::
No need Pallets
Motor::
Siemens standars
Color::
customized
After Warranty Service:
Video technical support

Quick Details

Type:
lightweight concrete machine, Aac Block Making Plant
Brick Raw Material:
concrete,cement,sand,crushed stone,fly ash,
Production Capacity (Pieces/8 hours):
50000/100000/200000 m3
Brick size:
600*200*100/150/200
Place of Origin:
Shandong, China
Brand Name:
weida
Voltage:
380/415/440V(customerized)
Dimension(L*W*H):
depends
Core Components:
Siemens standars
Weight (KG):
100000 kg
Capacity:
30000M3/year
Key Selling Points::
automatic
Pallet size::
No need Pallets
Motor::
Siemens standars
Color::
customized
After Warranty Service:
Video technical support
automatic brick machines aac alc hebel panel block making plant cost Philippines
PRODUCT DESCRIPTION:

Aac Block Making Plant (Aerated Autoclaved Concrete Block Machine line)introduce

(1).introduction
Aerated concrete brick (light brick ) is the light and porous building material. It has light keeping temperature cant burn and other advantages . it can be made into many kinds of bricks (for example : 600×200×100,600×150×100 , 600×300×200, 600×200×150 ) ,they could be used industry building and common building . they are more and more popular in the world .in the future ,they will replace the Clay brick completely .

(2).Aerated concrete common conception
Common concrete density is usually 1600-2400kg/m3,but Aerated concrete are 500kg/m3,600kg/m3,700kg/m3.It has not the big grain ,main use silicon material (for example: coal ash , sand , stone dust and others ) ,through making the material small for example sand,they can be used directly if has enough degree of small (for example coal ash.Mixing calcium material lime cement water to a special slop , then add the aluminum dust and the additive. Make the aluminum dust and the special slop have a Chemical reflect,then produce Hydrogen to make the concrete slop to expanding or swell,foam . Next , put them into the curing room to concreting ,cutting steaming curing . last , there will become the light brick . the porous rate is 70-80%.

(3). Advantages
light weight
Aerated concrete density is usually 400-700kgs / m3, (according the market ti produce ),same as 1/3 of clay brick and 1/5 common concrete.So use the Light brick can reduce the weight of the build more ,and also reduce the beam of roof and pillar press best . then you can see ,it can save the material and cost ,it also fighting shaking .
keeping temperature It has many are porous ,the delivery heating coefficient is 0.9-0.22W/ (mk),the same as 1/4 or 1/5 of clay brick ,so it is best materials now in the world.

have many kinds material ,have lowest waste
Main Material :A:sand/ Flyash 65-70% B:cement 12-15% C:Lime powder 12-15% D: Gypsum 3-5% E: Aluminum 0.5kg/m3

Capacity description :
* Main raw material : Silica Sand
* Cutting machine size :
* (1) 2.6 m cutting machine,30000-45000m3/year (100-150m3/day ) ,land need 5000-8000m2
(2)4.2m cutting machine,50000-150000m3/year(160-500m2/day, land need 8000-15000m2
(3) 4.8meter cutting machine,150000-240000m3/year(500-800m2/day,land need 15000-20000m2
(4)6 meter cutting machine,200000-300000m3/year(700-1000m2/day, land need 25000-30000m2
* Mould net size(after cutting):2x1.2x0.6/4.2x1.2x0.6m /4.8x1.2x0.6m / 6x1.2x0.6m
* Autoclave: Φ2x31.5m , Φ2.5x32m , Φ2.68x2m , depend on different capacity .
Product Description
Brand Name
weda
Place of Origin
Shandong, China
Capacity
30000M3/year
Type
AAC/ALC block machine
Certification
CE/ISO9001
Processing
Brick Cutting Machine
Method
Autoclaved Aerated Concrete
Brick Raw Material
Concrete
Automatic:
Yes
Voltage:
380/415/440V(customerized)
Dimension(L*W*H)
depends
condition
new
Warranty
1 year
Key Selling Points:
automatic
Pallet size:
No need Pallets
Product Name:
lightweight Aac Block brick Manufacturing Machine
Block Type:
AAC/ALC block
Motor:
Siemens standards
Color:
customized
Workers:
12
PLC:
Siemens standards
Switch:
Schneider
Packing & Delivery
Certifications
Company Profie
About Us
Shandong Weida Construction Machinery CO., Ltd （was renamed as Shandong weida environmental protection machinery co.,ltd) is located in Linyi City, Shandong Province, China. With 20 million USD investment and 53,000 square meters area, Its main business covers autoclaved aerated concrete production line, cement brick machine, high-strength gypsum powder extraction equipment. It has advanced processing equipment, exquisite professional technology and rich manufacturing experience. It has 18 professional senior technical personnel and more than 350 professional technical workers.

Products sold in more than 20 provinces and cities, more than 50 regions, some products export to Russia, Vietnam, South Korea, India, Singapore, Australia and more than 100 countries and regions. The company has passed ISO9001 management system and CE certificate,THe machinery absorb German mechanical design manufacturing experience,provide comprehensive technical service,including:investment proposal,construction planning,quality warranty,after-sales service,problem-solving etc.
Based on the business philosophy of “complete solution,complete service,creat more value for customers”,Weida machinery persistes in “service wins” and continiously improves its operational management and innovation capabilities to provide global customers with safe,efficient,reliable,enviromentally friendly products.
FAQ
Q1. What is the advantage about your company? A1. Customer No-worries service, Take "reaching production when put into operation" as the work goal Q2. Why should I choose your products? A2. Professional Leadership Gather the directors of each company to make the equipment that best meets the needs of customers Q3. The logo and the color can be customized? A3. Yes, we welcome you to sample custom Q4. Any other good service your company can provide? A4. Yes, During installation, the technical department shall participate in drawing review to eliminate errors caused by installation During commissioning, organize the company's internal on-site cross acceptance evaluation first, and strictly control the quality control standards
