Quick Details
-
Brand Name:
-
cf
-
Model Number:
-
A441T
-
Max. Current:
-
16A
-
Type:
-
Oven Parts, Oven Parts
-
Product name:
-
oven rotary switch
-
Material:
-
PA66
-
current:
-
10/16A
-
Voltage:
-
250/400V
-
Package:
-
Standard Packing
-
Packing:
-
Carton
-
product name:
-
Shaft selector switch
Quick Details
-
Whether the smart:
-
NO
-
Max. Voltage:
-
250V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
cf
-
Model Number:
-
A441T
-
Max. Current:
-
16A
-
Type:
-
Oven Parts, Oven Parts
-
Product name:
-
oven rotary switch
-
Material:
-
PA66
-
current:
-
10/16A
-
Voltage:
-
250/400V
-
Package:
-
Standard Packing
-
Packing:
-
Carton
-
product name:
-
Shaft selector switch
Specification
|
Rating |
16A 250VAC T150(TUV) |
|
Operating temperature |
-25~150℃ |
| Contact resistance | 30mΩ Max |
| Insulation resistance | 100mΩ Min |
| Electrical life | 10000cycles(16A 250VAC T150) |
| Applicable standard | IEC61058-1:2002+A2 |
Material list
| Contact leg | Beryllium copper alloy |
| Contact | Silver alloy |
| Terminals | Brass T=0.8mm |
| Case | PA66 |
