Quick Details
-
Brand Name:
-
GOLD
-
Model Number:
-
GDQ
-
Product name:
-
Water Well Logger Borehole Logging Equipment
-
Application:
-
borehole logging, water well logging
-
Detection depth:
-
0-3000M
-
Measuring parameter:
-
SP, Caliper, Resistivity, Gamma, Sonic etc.
-
Speed measurement range:
-
0 ~ 9999m/h
-
Deep optical pulse signal:
-
3600 pulses per meter
-
Figure out the depth of the graph:
-
1:10; 1:50. 1:100. 1:0; 1, 50, 0, etc
-
probe diameter:
-
40mm/50mm
-
Measuring range:
-
Water Well Logger Borehole Logging Equipment
Quick Details
-
Warranty:
-
1 Year
-
Power:
-
Electronic
-
Place of Origin:
-
Chongqing, China
-
Brand Name:
-
GOLD
-
Model Number:
-
GDQ
-
Product name:
-
Water Well Logger Borehole Logging Equipment
-
Application:
-
borehole logging, water well logging
-
Detection depth:
-
0-3000M
-
Measuring parameter:
-
SP, Caliper, Resistivity, Gamma, Sonic etc.
-
Speed measurement range:
-
0 ~ 9999m/h
-
Deep optical pulse signal:
-
3600 pulses per meter
-
Figure out the depth of the graph:
-
1:10; 1:50. 1:100. 1:0; 1, 50, 0, etc
-
probe diameter:
-
40mm/50mm
-
Measuring range:
-
Water Well Logger Borehole Logging Equipment
Geophysical SP Potential Resistivity Gamma Well Logger Borehole Logging Equipment Caliper Logging Equipment
Borehole Well Logging Tool proved invaluable for quickly and accurately determining fresh water producing formations from borehole logs in underground water exploration from 100m to 3000m depth borehole.
Well logging tool portable, easy use instruments have proven quickly identifying fresh water producing formations from well logs. it enables the driller or geologist/geophysicist to check the critical characteristics of a potential well that are unobtainable by other methods.
The well logging equipment equipped with a basic combination gamma and electric logging probe positively identify fresh water formations, precisely delineate their thickness, and reveal the undesirable intrusion of clay lenses or brackish water.
Function:
'16'Short Normal Resistivity
'64' Long Normal Resistvity
Natural Gamma
Temperature
SP/SPR
Caliper
Sonic
Probes of Geophysical SP Potential Resistivity Gamma Well Logger Borehole Logging Equipment Caliper Logging Equipment
|
No. |
Name |
Parameters |
|
1 |
Resistivity and gamma |
SP, apparent resistivity, natural gamma |
|
2 |
Combined porbe |
16/64 resistivity, SP, natural gamma, temperature, SPR |
|
3 |
RES and IP |
16/64 resistivity, SP, IP |
|
4 |
Three component magnetometer |
Magnetic Tri-component |
|
5 |
Temperature and fluid resistivity |
Temperature, fluid resistivity |
|
6 |
Thee arm |
Diameter, liquid level |
|
7 |
Sonic |
Travel time, equation of time, amplitude |
|
8 |
Combined density |
Density, laterolog resisitivity, natural gamma, sp,caliper |
|
9 |
Neutron and gamma |
Natural gamma, porosity |
