Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Dimension(Long * Breadth * High):
-
7085*2313*2710 mm
-
Machine Weight:
-
7600 kg
-
Bucket capacity:
-
0.6 m3
-
Length(with bucket on ground):
-
7085mm
-
Total exhaust of cylinder:
-
4.5L
-
Rated Power:
-
70KW
-
Engine Model:
-
WD WP4G95E221
-
Max. digging depth:
-
4405mm
-
Rated digging bucket capacity:
-
0.3m3
-
Max. Dump reach:
-
845mm
-
Wheelbase:
-
2155.5mm
-
Load Bucket width:
-
2313mm
-
Certification:
-
ISO CE GOST EPA
Quick Details
-
Engine Brand:
-
cum-mins
-
Power:
-
92 KW
-
Brand Name:
-
Chang-lin
-
Place of Origin:
-
Jiangsu, China
-
Dimension(Long * Breadth * High):
-
7085*2313*2710 mm
-
Machine Weight:
-
7600 kg
-
Bucket capacity:
-
0.6 m3
-
Length(with bucket on ground):
-
7085mm
-
Total exhaust of cylinder:
-
4.5L
-
Rated Power:
-
70KW
-
Engine Model:
-
WD WP4G95E221
-
Max. digging depth:
-
4405mm
-
Rated digging bucket capacity:
-
0.3m3
-
Max. Dump reach:
-
845mm
-
Wheelbase:
-
2155.5mm
-
Load Bucket width:
-
2313mm
-
Certification:
-
ISO CE GOST EPA
Chang-lin Backhoe Loader 630A
Features of Backhoe Loader 630A:
1. Equipped with WD DETUZ engine
2. 4 forward & 4 reverse synchromesh mechanical shift transmission
3. Combined seal cylinder obtains high seal performance and more reliability
4. Improved loader and backhoe performance
5. CARRARO wet type rear axle with multi-disc brake& CARRARO front axle
6. New-type cab with more space, increases comfort and visibility
7. With 2 wheel driving or 4 wheel driving for option
Specifications of Backhoe Loader 630A:
|
Overall Dimension |
|||
|
1 |
Length(with bucket on ground) |
7085(mm) |
|
|
2 |
Width |
2313(mm) |
|
|
3 |
Load Bucket width |
2313(mm) |
|
|
4 |
Height(To the top of the cab) |
2710 (mm) |
|
|
5 |
Height(To the top of the digging pole) |
3424 (mm) |
|
|
6 |
Wheelbase |
2155.5(mm) |
|
|
7 |
Back wheel Tread |
1700(mm) |
|
|
8 |
Fore wheel Tread |
1880(mm) |
|
|
9 |
Min. ground clearance |
355(mm) for 2WD 275(mm) for 4WD |
|
|
Main Loading Technical Specification |
|||
|
1 |
Rated load |
1700(Kg) |
|
|
2 |
Operating weight |
7600KG |
|
|
3 |
Max lifting capability |
>2500KG |
|
|
4 |
Rated load bucket capacity |
1.0(m 3 ) |
|
|
5 |
Max. load breakout force |
>60kN |
|
|
6 |
Max. dump clearance |
2714(mm) |
|
|
7 |
Max. Dump reach |
845(mm) |
|
|
8 |
Dump angle at any position |
≥43.5° |
|
|
9 |
Min. turning radius |
||
|
(1) Outside of bucket |
5280(mm) for 2WD 5670(mm) for 4WD |
||
|
(2) Center of front wheel |
3795 (mm) for 2WD 4380(mm) for 4WD |
||
|
10 |
Lifting time of loading bucket |
≤4.5(sec.) |
|
|
11 |
Lowering time of loading bucket |
≤7.5(sec.) |
|
|
12 |
Dumping time |
≤1.5(sec.) |
|
|
13 |
Traveling speed(Km/h),4 forward and 4 reverse |
||
|
Main Digging Technical Specification |
|||
|
1 |
Rated digging bucket capacity |
0.3(m 3 ) |
|
|
2 |
Max. digging depth |
4405(mm) |
|
|
3 |
Max. digging force |
>50±10%kN |
|
|
4 |
Max. digging radius |
5481(mm) |
|
|
5 |
Max. dumping height |
3737(mm) |
|
|
Diesel engine |
|||
|
1 |
Model |
WD WP4G95E221 |
|
|
2 |
Type |
Direct injection. Turbocharged. Water cooling |
|
|
3 |
Rated output |
70 (kW) |
|
|
4 |
Total exhaust of cylinder |
4.5(L) |
|
|
5 |
Inter-bore of cylinder/stroke |
102/130(mm) |
|
|
6 |
Voltage of starting motor |
12(V) |
|
|
7 |
Rated speed |
2200(r/min) |
|
|
8 |
Max. Torque |
380(N.M) |
|
|
9 |
Starting type |
Electric |
|
|
10 |
Min. specific fuel consumption |
216(g/Kw.h) |
|
|
Transmission System |
|||
|
1. Torque Converter |
|||
|
1 |
Model |
CARRARO |
|
|
2 |
Cooling type |
Pressure oil circulating |
|
|
2. Transmission case |
|||
|
1 |
Model |
CARRARO |
|
|
2 |
Type |
Synchromesh mechanical shift |
|
|
3 |
Gear shift posit |
4 Forward and 4 reverse gears |
|
|
3. Axle and Tire |
|||
|
1 |
Model |
CARRARO |
|
|
2 |
Type of main reducer |
spiral bevel gear, single stage |
|
|
3 |
Type of final reducer |
Single stage planetary |
|
|
4 |
Max. steering angle |
55° |
|
|
5 |
Tire type |
4WD fore tire12-16.5NHS-10PR |
|
|
2WD fore tire11L-16F3-12PR |
|||
|
Rear tire 19.5L-24R4-12PR |
|||
|
Working Device Hydraulic System |
|||
|
1 |
Model of oil pump |
JHP2063C |
|
|
2 |
System pressure |
210(kgf/cm 2 ) |
|
|
3 |
Model of load valve |
ZL20.3S4C-00 |
|
|
4 |
Model of excavate valve |
WJ20.7SC3-00 |
|
|
Steering System |
|||
|
1 |
Type |
Fore wheel Steering |
|
|
2 |
Model of steering pump |
JHP2063C |
|
|
3 |
Model of Redirector |
BZZ5-E160B+ FKB-3022 |
|
|
4 |
System pressure |
140(kgf/cm 2 ) |
|
|
Oil Capacity |
|||
|
1 |
Fuel(diesel) |
151(L) |
|
|
2 |
Engine lubricating oil |
11(L) |
|
|
3 |
Oil for converter and gear box |
For 2WD |
18.5(L) |
|
For 4WD |
21(L) |
||
|
4 |
Oil for hydraulic system |
110(L) |
|
|
5 |
Oil for driving axles(F/R) |
7.6+17(L) |
|
