Quick Details
-
Power:
-
11.8kw
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
YC
-
Maximum Digging Height:
-
2900mm
-
Maximum Digging Depth:
-
2100MM
-
Machine Weight:
-
2000 kg
-
Max Digging Radius:
-
3860mm
-
Rated Speed:
-
12rmp
-
Overall dimensions:
-
2930*1100*2100mm
-
Track length*width:
-
1500mm*180mm
-
Bucket width:
-
400mm
-
Dumping height:
-
2385mm
-
Ground clearance:
-
380mm
-
Model Number:
-
YCW-12,YCW-18-YCW-20
-
Key words:
-
crawler excavator
-
Grade Ability:
-
35
-
Arm Length:
-
2050mm
-
Delivery time:
-
Within 7 Days
Quick Details
-
Operating Weight:
-
3ton, 1ton, 2ton, 0.8 TON, 1.8Ton, 1.2ton, 1.5TON
-
Bucket capacity:
-
0.04m3
-
Engine Brand:
-
Kubota
-
Power:
-
11.8kw
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
YC
-
Maximum Digging Height:
-
2900mm
-
Maximum Digging Depth:
-
2100MM
-
Machine Weight:
-
2000 kg
-
Max Digging Radius:
-
3860mm
-
Rated Speed:
-
12rmp
-
Overall dimensions:
-
2930*1100*2100mm
-
Track length*width:
-
1500mm*180mm
-
Bucket width:
-
400mm
-
Dumping height:
-
2385mm
-
Ground clearance:
-
380mm
-
Model Number:
-
YCW-12,YCW-18-YCW-20
-
Key words:
-
crawler excavator
-
Grade Ability:
-
35
-
Arm Length:
-
2050mm
-
Delivery time:
-
Within 7 Days
Products Description
Main Features
1. Engine:Loop/Briggs&Stratton/ Kubota (Euro V . EPA)
2. Hydraulic pump (gear pump) is easy to maintain, long life
3. Strong lift and dig performance helps you get the job done faster. The retractable undercarriage lets you access and work in the tightest areas. Dig-to-blade and dozer float features allow for easy clean up.
4. Multiple valves under the operating handle,The benefit of less effort and improved control is in your hands!
5. Rubber track no damage to cement, tile floor
6. Diesel level gauge: Check engine oil when it is not easy to start
Product Paramenters
Machine 1-Year Warranty Service and Support Customization!
>>>Click Here To Get The Best Price!
|
Model
|
YCW-08
|
YCW-10
|
YCW-12
|
YCW-15
|
|
Operation weight
|
800kg
|
1000kg
|
1200kg
|
1500kg
|
|
Engine
|
Koop 192F
|
Koop 192F
|
Koop 192F
|
Koop
|
|
Power
|
8.6kw
|
8.6kw
|
8.6kw
|
8.6kw
|
|
Bucket capacity
|
0.025m²
|
0.025m²
|
0.025m
|
0.025m²
|
|
Machine size
|
2000*720*1150
|
2200*940*2250
|
2130*960*2250
|
2200*1100*2150
|
|
Max.dig depth
|
1300mm
|
1650mm
|
1650mm
|
1650mm
|
|
Max.dig height
|
2400mm
|
2580mm
|
2580mm
|
2550mm
|
|
Min.swing radius
|
1100mm
|
1100mm
|
1190mm
|
1190mm
|
|
Max.dig radius at groundine
|
2540mm
|
2500mm
|
2500mm
|
2500mm
|
|
Gradeability
|
30°
|
35°
|
35°
|
35°
|
|
Model
|
YCW-17
|
YCW-18
|
YCW-20
|
YCW-25
|
|
Operation weight
|
1700kg
|
1800kg
|
2000kg
|
2200kg
|
|
Engine
|
Laidong 385
|
Kubota 722
|
Changchai 390
|
Laidong 385
|
|
Power
|
29kw
|
10.5kw
|
20kw
|
22kw
|
|
Bucket capacity
|
0.025m3
|
0.04m³
|
0.04m³
|
0.08m
|
|
Machine size
|
2280*1100*2200
|
2250*1100*2200
|
2400*1150*2200
|
3300*1300*2300
|
|
Max.dig depth
|
1900mm
|
2100mm
|
2150mm
|
2200mm
|
|
Max.dig height
|
2820mm
|
2900mm
|
2950mm
|
3500mm
|
|
Min.swing radius
|
2500mm
|
1190mm
|
2500mm
|
2500mm
|
|
Max.dig radius at groundine
|
2600mm
|
2600mm
|
2600mm
|
2600mm
|
|
Gradeability
|
35°
|
35°
|
45°
|
45°
|
Optional Accessories
All accessories are available here.
Support Multi-Function Operation, Cabin,Air conditioning,Swing boom , Telescopic crawler track function can be optional.
Use our Quick coupler(quick hitch) can add the attachment tools like: driller auger, hydraulic breaker hammer, trailer,20cm--100cm bucket, rake,gripper, wood grab and so on.
Mini excavator is designed for small works,small projects,in garden,farmland,municipal works,vegetable，greenhouse,digging trench. small engine, simple design, easy to operate and maintain.
