Quick Details
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
12V36W power supply
-
Output Frequency:
-
47-63Hz
-
Output Current:
-
3A±1%
-
AC input voltage range:
-
90-250V
-
AC impulse current:
-
0.35A
-
DC output voltage:
-
12V/24V ±0.5VDC
-
DC output power:
-
36W
-
Efficiency:
-
>80%
-
Waterproof rate:
-
IP67
-
Dimension(mm):
-
200(L)*30(W)*20(H)
-
Weight:
-
0.26kgs
Quick Details
-
Output Power:
-
36W
-
Input Voltage:
-
90-250V
-
Output Voltage:
-
12V/24V ±0.5VDC
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
12V36W power supply
-
Output Frequency:
-
47-63Hz
-
Output Current:
-
3A±1%
-
AC input voltage range:
-
90-250V
-
AC impulse current:
-
0.35A
-
DC output voltage:
-
12V/24V ±0.5VDC
-
DC output power:
-
36W
-
Efficiency:
-
>80%
-
Waterproof rate:
-
IP67
-
Dimension(mm):
-
200(L)*30(W)*20(H)
-
Weight:
-
0.26kgs
Why Choose Us
Product Parameters
1.Built-in EMI filter
2.Low output ripple noise
3.Over load,over voltage,short circuit
4.CE&Rohs approval
Features:
Aluminum housing,100% waterproof,IP67
Efficiency:>80%
2 years warranty
OEM, ODM are acceptable
|
Model
|
12V36W IP67/24V36W IP67
|
|
|
|
Input
|
AC Voltage
|
90-250V
|
|
|
|
Frequency
|
47-63Hz
|
|
|
|
AC current
|
0.35A
|
|
|
Output
|
DC Voltage
|
12V/24V ±0.5VDC
|
|
|
|
Rated power
|
36W
|
|
|
|
Current range
|
3A±1%
|
|
|
Protection
|
Overload
|
100% overloading
|
|
|
|
Short circuit
|
Auto recovery
|
|
|
|
Over voltage
|
≤255V
|
|
|
|
Over temperature
|
≤80°C
|
|
|
Others
|
Waterproof rate
|
IP67
|
|
|
|
Cooling
|
by convection
|
|
|
|
Efficiency
|
>80%
|
|
|
|
Housing materials
|
Aluminum
|
|
|
|
Dimension(mm)
|
200（L）*30（W）*20（H）
|
|
|
|
Weight
|
0.26kgs
|
|
