Quick Details
-
Weight (KG):
-
260
-
Voltage:
-
220V 50hz 2KW
-
Place of Origin:
-
Liaoning, China
-
Dimension(L*W*H):
-
1350 * 1150 * 2260mm
Quick Details
-
Function:
-
FILLING, Sealing
-
Packaging Type:
-
Bags
-
Packaging Material:
-
Nylon
-
Weight (KG):
-
260
-
Voltage:
-
220V 50hz 2KW
-
Place of Origin:
-
Liaoning, China
-
Dimension(L*W*H):
-
1350 * 1150 * 2260mm
Product Description
Automatic pyramid tea bag filling and packing machine
Application:
Be used for automatically packing products as green tea ,black tea,flower tea ,health tea,,granule tea,coffee granule and so on .
Main feature:
1.It can automatically complete cutting, bag making, measuring, filling, sealing, cutting, counting, and can be configured with coding functions according to needs.
2.Using touch screen operation PLC control, driving stepper motor to control bag length, stable performance, convenient
adjustment, and accurate detection.
3. Intelligent temperature controller with PID adjustment ensures that the temperature error range is controlled within 1 ℃.
Be used for automatically packing products as green tea ,black tea,flower tea ,health tea,,granule tea,coffee granule and so on .
Main feature:
1.It can automatically complete cutting, bag making, measuring, filling, sealing, cutting, counting, and can be configured with coding functions according to needs.
2.Using touch screen operation PLC control, driving stepper motor to control bag length, stable performance, convenient
adjustment, and accurate detection.
3. Intelligent temperature controller with PID adjustment ensures that the temperature error range is controlled within 1 ℃.
Technical parameters
|
Model No.:
|
ZF90
|
|
Capacity:
|
70-100bags/Min(Determined by packing material)
|
|
Bag type:
|
Triangle 3-dimensional sealing/flat sealing
|
|
Filling range:
|
1-10g
|
|
Measuring methods:
|
Electronic scale sensor weighing
|
|
Film type:
|
Nylon, Polyester net non-woven fabrics,. ultrasonic sealing materials
|
|
Film thickness：
|
0.04-0.06mm
|
|
Bag size:
|
Bag size: 30-180mm long and 20-75mm wide
|
|
Packing film:
|
120mm、140mm、160mm
|
|
Sealing method:
|
Ultrasonic sealing
|
|
Air consumption:
|
0.6m3/min 0.8Mpa
|
|
Total power:
|
AC220V/50Hz/2kw
|
|
Dimension:
|
1350 * 1150 * 2260mm
|
|
Net weight:
|
260-410kg
|
Details
Inner structure
APPLICATION:
FAQ
Q1: Where is your factory? How can I visit there?
A1: Our factory location is Liaoyang City , Liaoning Province, China.If want to visit our company , you can fly to Shenyang
Taoxian Airport .
Q2: Do you have technicians for installation?
A2: We are responsible for the installation in your country, you can also arrange your staffs to our factory to learn how to
operate the machines, after purchased ,we offer English manual book and operation videos.
Q3: What's your advantages compared to your competitors?
A3: Quality and experience, as evidenced by 40 patents and over 35 years of experience.
Q4: What's payment you accept?
A4: T/T, Western Union, L/C, Ali Pay, etc
A1: Our factory location is Liaoyang City , Liaoning Province, China.If want to visit our company , you can fly to Shenyang
Taoxian Airport .
Q2: Do you have technicians for installation?
A2: We are responsible for the installation in your country, you can also arrange your staffs to our factory to learn how to
operate the machines, after purchased ,we offer English manual book and operation videos.
Q3: What's your advantages compared to your competitors?
A3: Quality and experience, as evidenced by 40 patents and over 35 years of experience.
Q4: What's payment you accept?
A4: T/T, Western Union, L/C, Ali Pay, etc
Our Company
Liaoning Fuyi Machinery is one of the most famous centrifuge manufacturers in China with 30 years mature experience and techniques. "We also manufacture various filling and packing machines, which are widely used. Nowadays our customers are from global market which give good feedback for our products. We promise supply customers the best quality and service in China.
Product packaging
Plywood case export packaging
Ship by sea
30-60 days
