Quick Details
-
Efficiency:
-
85%min
-
DC Voltage:
-
12V
-
Rated Current:
-
3A
-
Rated Power:
-
36W
-
Voltage Tolerance:
-
±5%
-
Line Regulation:
-
±1%
-
Load Regulation:
-
±5%
-
Working Temp:
-
-10~+65℃
Quick Details
-
Place of Origin:
-
China
-
Voltage Range:
-
90~264Vac(Normal Reated Input Voltage is 100~240Vac)
-
Frequency Range:
-
47/63Hz
-
Efficiency:
-
85%min
-
DC Voltage:
-
12V
-
Rated Current:
-
3A
-
Rated Power:
-
36W
-
Voltage Tolerance:
-
±5%
-
Line Regulation:
-
±1%
-
Load Regulation:
-
±5%
-
Working Temp:
-
-10~+65℃
Why Choose Us
Product Parameters
1. Universal Input 100~240VAC 50/60Hz
2. over voltage protection: 120%min
3. over current protection: 120%min
4. over protection
5.Short-circuit protection: automatic recovery
6. Load regulation: ± 5%
7. High Efficiency
8.TWO YEAR WARRANTY
|
Input
|
Voltage Range
|
90~264Vac(Normal Reated Input Voltage is 100~240Vac)
|
|
|
Frequency Range
|
47/63Hz
|
|
|
Efficiency
|
85%min
|
|
Output
|
DC Voltage
|
12V
|
|
|
Rated Current
|
3A
|
|
|
Rated Power
|
36W
|
|
|
Voltage Tolerance
|
±5%
|
|
|
Line Regulation
|
±1%
|
|
|
Load Regulation
|
±5%
|
|
Enviroment
|
Working Temp
|
-10~+65℃
|
|
|
Working Humidity
|
20~90% RH non-condensing
|
|
|
Storange Temp., Humidity
|
-20~+85℃, 10~95%RH
|
|
Others
|
Certificates
|
CE-EMC CE-LVD RoHS
|
|
|
DC plug
|
5.5x2.1mm, 5.5x2.5mm
|
|
|
Packing
|
Brown paper box, with AC cable
|
