Quick Details
-
Market Segement:
-
Engineering transportation
-
Engine Capacity:
-
> 8L
-
Gross Vehicle Weight:
-
≤5T
-
Drive Wheel:
-
4X2
-
After-sales Service Provided:
-
Video technical support, Return and Replacement, Online support, Free spare parts, Field maintenance and repair service
-
Place of Origin:
-
Hubei, China
-
Engine Brand:
-
Sinotruk
-
Dimensions (L x W x H) (mm):
-
5900x2100x2300
-
Cargo Tank Dimension:
-
3600x1800x600mm
-
Model NO.:
-
ZZ1047D3414C145
-
Tire Design:
-
Tubeless
-
Clutch:
-
Reinforced Diaphragm Clutch, Diameter 430mm
-
Engine Model:
-
YN4102QBZL
-
Brand:
-
Sinotruk
-
Color:
-
Customized Request
-
Tipping System:
-
Hydraulics System
-
Tare Weight:
-
2705kgs
-
Horse Power:
-
116 HP
Quick Details
-
Condition:
-
New
-
Horsepower:
-
110 - 250hp
-
Emission Standard:
-
Euro 2
-
Market Segement:
-
Engineering transportation
-
Engine Capacity:
-
> 8L
-
Gross Vehicle Weight:
-
≤5T
-
Drive Wheel:
-
4X2
-
After-sales Service Provided:
-
Video technical support, Return and Replacement, Online support, Free spare parts, Field maintenance and repair service
-
Place of Origin:
-
Hubei, China
-
Engine Brand:
-
Sinotruk
-
Dimensions (L x W x H) (mm):
-
5900x2100x2300
-
Cargo Tank Dimension:
-
3600x1800x600mm
-
Model NO.:
-
ZZ1047D3414C145
-
Tire Design:
-
Tubeless
-
Clutch:
-
Reinforced Diaphragm Clutch, Diameter 430mm
-
Engine Model:
-
YN4102QBZL
-
Brand:
-
Sinotruk
-
Color:
-
Customized Request
-
Tipping System:
-
Hydraulics System
-
Tare Weight:
-
2705kgs
-
Horse Power:
-
116 HP
Product Description
Advantages:
1. Oil Saving--two kinds of technology route (electric control common rail and EGR), engine characteristic performance curve improvement, entire car optimizing assembly, empty / full load switch, the latest streamline driving cab reducing wind resistance effectively, reducing self weight by 200--500kg, and etc.
2. Safety--drum brake, tubeless tire, exhaust valve brake technique application, rear axle brake shoe widening, and etc.
3. Driving comfort-- New style air bag seat, four point floating suspension with anti-roll bar, damping device for the cab, double locking seat belt, outside sun shade, drum brake solving brake sway in case of over load, and etc
4. Reliability--all the assembly has passed extremely harsh condition experiments and the verification of over 2 years in bad use condition.
5. Low application cost--large use quantity, complete service and accessory networks and low price.
Specification
|
Cabin
|
1880 single row with a sleeper, with A/C
70° hydraulically tillable to the front as attached photo for ref. |
|
|
|
Vehicle Main Dimensions
|
(L x W x H)mm
|
5900×2100×2300
|
|
|
|
Wheel base (mm)
|
3360
|
|
|
|
Wheel track (front/rear) (mm)
|
2022/1830
|
|
|
|
Approach/Departure angle(°)
|
19/27
|
|
|
Weight in KGS
|
Tare Weight
|
2705kg
|
|
|
|
Loading Capacity
|
5000kg
|
|
|
|
Front axles loading capacity
|
1x2400
|
|
|
|
Rear axles loading capacity
|
1x4200
|
|
|
Max. driving speed(km/h)
|
|
98
|
|
|
Engine
|
Brand
|
Yunnei
|
|
|
|
Model
|
YN4102QBZL
|
|
|
|
Type
|
4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling
|
|
|
|
Horse Power(HP)
|
116HP
|
|
|
|
Emission standard
|
Euro 2
|
|
|
Gearbox
|
WLY646, 5 forwards & 1reverse
|
|
|
|
Clutch
|
Reinforced diaphragm clutch, diameter 430mmClutch
|
|
|
|
Steering Gear
|
ZF 8098,power steering, hydraulic steering with power assistance
|
|
|
|
Fuel tank (L)
|
120
|
|
|
|
Tire
|
7.00R16 All steel radial tire is available , 6 pieces with 1spare
|
|
|
|
Brakes
|
Service brake: dual circuit compressed air brake
Parking brake :(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust valve brake |
|
|
|
Dump body thickness
|
Side
|
3mm in high tensile strength steel Q345/B
|
|
|
Front
|
3mm in high tensile strength steel Q345/B
|
|
|
Bottom
|
4mmin high tensile strength steel Q345/B
|
|
Tipping hydraulics
|
Tipping system
|
Complete set hydraulics system
|
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
