Quick Details
-
Storage Type:
-
Indoor
-
The charging ratio:
-
1C
-
The discharge rate:
-
1C
-
Battery Size:
-
26-260Ah
-
Brand Name:
-
SUNARK
-
Model Number:
-
DC12-26~DC12-260
-
Place of Origin:
-
Anhui, China
-
Weight:
-
19Kg
-
Cells Per Unit:
-
6
-
Voltage Per Unit:
-
12
-
Capacity:
-
200Ah@10hr-rate to 1.80V per cell @25°C
-
Design Life:
-
12 years (Float charging)
-
Standby Use Voltage:
-
13.6V~13.8V @25°C
-
Cycle Use Voltage:
-
14.6V~14.8V @25°C
-
Operating Temperature Range:
-
Discharge: -20°C~60°C Charge: 0°C~50°C Storage: -20°C~60°C
-
Normal Operating Temperature Range:
-
25°C ± 5°C
-
Self Discharge:
-
Monthly Self-discharge ratio is less than 3% at 25°C.
-
Container Material:
-
A.B.S. UL94-HB, UL94-V0 Optional
Quick Details
-
Chargeable:
-
Yes
-
Battery Type:
-
AGM
-
Cycle Life:
-
6000 Cycle
-
Storage Type:
-
Indoor
-
The charging ratio:
-
1C
-
The discharge rate:
-
1C
-
Battery Size:
-
26-260Ah
-
Brand Name:
-
SUNARK
-
Model Number:
-
DC12-26~DC12-260
-
Place of Origin:
-
Anhui, China
-
Weight:
-
19Kg
-
Cells Per Unit:
-
6
-
Voltage Per Unit:
-
12
-
Capacity:
-
200Ah@10hr-rate to 1.80V per cell @25°C
-
Design Life:
-
12 years (Float charging)
-
Standby Use Voltage:
-
13.6V~13.8V @25°C
-
Cycle Use Voltage:
-
14.6V~14.8V @25°C
-
Operating Temperature Range:
-
Discharge: -20°C~60°C Charge: 0°C~50°C Storage: -20°C~60°C
-
Normal Operating Temperature Range:
-
25°C ± 5°C
-
Self Discharge:
-
Monthly Self-discharge ratio is less than 3% at 25°C.
-
Container Material:
-
A.B.S. UL94-HB, UL94-V0 Optional
Products Description
|
Model
|
Nominal Voltage
|
Capacity
|
Capacity
|
Dimension
|
|
|
|
||||
|
|
|
|
|
Length
|
Width
|
Height
|
Total Height
|
||||
|
|
V
|
Ah
|
Ah
|
mm/inch
|
mm/inch
|
mm/inch
|
mm/inch
|
||||
|
DC12-26
|
12
|
26
|
C20/1.75VPC
|
166/6.54
|
176/6.93
|
125/4.92
|
125/4.92
|
||||
|
DC12-30
|
12
|
30
|
C20/1.75VPC
|
195/7.68
|
130/5.12
|
155/6.10
|
168/6.61
|
||||
|
DC12-40
|
12
|
40
|
C20/1.75VPC
|
198/7.80
|
166/6.54
|
169/6.65
|
169/6.65
|
||||
|
DC12-50
|
12
|
50
|
C20/1.75VPC
|
250/9.84
|
160/6.30
|
178/7.01
|
183/7.20
|
||||
|
DC12-55
|
12
|
55
|
C20/1.75VPC
|
229/9.02
|
138/5.43
|
211/8.31
|
216/8.50
|
||||
|
DC12-65
|
12
|
65
|
C20/1.75VPC
|
350/13.78
|
167/6.57
|
182/7.17
|
182/7.17
|
||||
|
DC12-80
|
12
|
80
|
C20/1.75VPC
|
350/13.78
|
167/6.57
|
182/7.17
|
182/7.17
|
||||
|
DC12-100
|
12
|
100
|
C20/1.75VPC
|
328/12.91
|
172/6.77
|
215/8.46
|
220/8.66
|
||||
|
DC12-120
|
12
|
120
|
C20/1.75VPC
|
407/16.02
|
177/6.97
|
225/8.86
|
225/8.86
|
||||
|
DC12-134
|
12
|
134
|
C20/1.75VPC
|
340/13.39
|
173/6.81
|
280/11.02
|
287/11.30
|
||||
|
DC12-145
|
12
|
145
|
C20/1.75VPC
|
340/13.39
|
173/6.81
|
280/11.02
|
287/11.30
|
||||
|
DC12-150
|
12
|
150
|
C20/1.75VPC
|
483/19.02
|
170/6.69
|
241/9.49
|
241/9.49
|
||||
|
DC12-160
|
12
|
160
|
C20/1.75VPC
|
532/20.94
|
207/8.15
|
214/8.43
|
219/8.62
|
||||
|
DC12-180
|
12
|
180
|
C20/1.75VPC
|
532/20.94
|
207/8.15
|
214/8.43
|
219/8.62
|
||||
|
DC12-190
|
12
|
190
|
C20/1.75VPC
|
532/20.94
|
207/8.15
|
214/8.43
|
219/8.62
|
||||
|
DC12-200
|
12
|
200
|
C20/1.75VPC
|
522/20.55
|
240/9.45
|
219/8.62
|
224/8.82
|
||||
|
DC12-225
|
12
|
225
|
C20/1.75VPC
|
522/20.55
|
240/9.45
|
219/8.62
|
224/8.82
|
||||
|
DC12-230
|
12
|
230
|
C20/1.75VPC
|
521/20.51
|
269/10.59
|
204/8.03
|
209/8.23
|
||||
|
DC12-260
|
12
|
260
|
C20/1.75VPC
|
521/20.51
|
268/10.55
|
220/8.66
|
225/8.86
|
||||
