Quick Details
-
Key words:
-
ftth drop wire cable
-
Packing:
-
Plywood Reel/customized
-
Length:
-
2000M/box or Optional
-
Jacket Material:
-
PVC LSZH
-
Certification:
-
CE/ROHS/ISO9001
-
Product name:
-
Indoor FTTH Fiber Optical Drop Wire
-
Fiber Type:
-
G657 A1 A2
-
Application:
-
Long distance/LAN communication/Outdoor communication
-
Leading Time:
-
3-15 days
-
Warranty:
-
30years
Quick Details
-
Brand Name:
-
Feiboer
-
Model Number:
-
GJYXCH
-
Place of Origin:
-
Guangdong, China
-
Key words:
-
ftth drop wire cable
-
Packing:
-
Plywood Reel/customized
-
Length:
-
2000M/box or Optional
-
Jacket Material:
-
PVC LSZH
-
Certification:
-
CE/ROHS/ISO9001
-
Product name:
-
Indoor FTTH Fiber Optical Drop Wire
-
Fiber Type:
-
G657 A1 A2
-
Application:
-
Long distance/LAN communication/Outdoor communication
-
Leading Time:
-
3-15 days
-
Warranty:
-
30years
FTTH fig8 steel wire messenger GJYXCH 2 core optic butterfly flat fibers drop cable with self support steel wire messenger
Product Features:
• Bow-tie type cross-section design, LZSH or PVC jacket
• Two parallel steel wire or FRP as strength member to protect the fiber and provide adequate tension and pressure
• Flex durable fiber to provide greater bandwidth and enhance network transmission characteristics
• Easy peeled off, light weight,small size, unique groove design, easy fo r maint a nce
Applications
• Indoor wiring system
• FTTH, terminal system
• Indoor shaft,building wiring
|
Type |
Fiber attenuation ( +20 ℃ ) |
OFL |
Band Width |
10G Ethernet link length |
Minimum bending radius |
|||
|
Condition |
1310/1550nm |
850/1300nm |
850/1300nm |
850nm |
850nm |
/ |
||
|
Typical value |
MAX |
Typical value |
MAX |
|||||
|
Unit |
dB/km |
dB/km |
dB/km |
dB/km |
MHZ.km |
MHZ.km |
m |
mm |
|
G657A1 |
0.36/0.22 |
0.5/0.4 |
10 |
|||||
|
G657A2 |
0.36/0.22 |
0.5/0.4 |
7.5 |
|||||
|
OM3 |
3.0/1.0 |
3.5/1.5 |
≥1500/500 |
≥2000 |
≤300 |
30 |
||
|
OM4 |
3.0/1.0 |
3.5/1.5 |
≥3500/500 |
≥4700 |
≤550 |
30 |
||
Storage and use temperature: -40 °C to +70 °C.
