customized 9 watt led bulb pcb manufacture led mcpcb with rohs 94v 0 pcb

FOB Reference Price: Get Latest Price

≥1 Pieces

US $1

≥500 Pieces

US $0.5

Free Inquiry

Customized Request

Quick Details

Specification

Products Description

Street Light Series

Application:Street lighting and Tunnel lighting

High thermal conductivity of copper substrate

Raw material and finial PCB are all fully accord with UL standard

Applicable products:

Street lamp,Tunnel lamp,advertisement lamp,high shed lamp,Shooting lamp and other outdoor lighting.

4.Enable to customize PCB and make assembly.

Applications

Production capablity

Technical parameters and process capability of metal substarte(MCPCB)
ITEM	SPECIFICATION
Surface	LF HASL,immersion gold,immersion siliver,OSP
Layer	Single side,double sided Multilayer and special structure
Maximum PCB size	LF HASL,immersion gold,immersion siliver,OSP
PCB thickness	0.4-3.0mm
Copper Foil thickness	H 1/2/3/4(oz)
Insulation layer thickness	50/75/100/125/150/175/200(um)
Metal Base thickness	AIuminum(1100/3003/5052/6061),Copper AIuminum
Metal Base thickness	0.5/0.8/1.0/1.2/1.6/2.0/3.2/5.0(mm)
Shaping	Die punching/CNC Route/V-Cut
Test	100% open&short test
Shaping tolerance	Die Punching<+- 0.05mm,CNC Route<+-0.15mm,V-CUT Thick residue>+-0.15mm
Hole tolerance	+-0.5mm
Min.Hole DIameter	Single side 0.5/Double sided PTH0.3MM
Solder mask	green/white/black/red/yellow
Min.letter height	0.8mm
Min.line space	0.15
Min.letter width	0.15
Sile screen color	blue/white/black/red/yellow
Sopecial hole	Spot facing/cup hole/buried via hole/buried tank
File format	Gerber,Protel,PowerPCB,AutoCAD etc
