Quick Details
-
Application:
-
Indoor
-
Supported OS:
-
Win 7 or Win 8 or Linux
-
Warranty:
-
13months
-
Touch screen resolution:
-
4096*4096
-
Display:
-
LCD,TFT,AUO or others
-
Material Feature:
-
Anti-dust,Anti-vandal
-
Logo:
-
By customers needs
-
Touch point:
-
1,2,4,6point is available
-
General size:
-
17"
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
AMH
-
Type:
-
touch screen kiosk
-
Application:
-
Indoor
-
Supported OS:
-
Win 7 or Win 8 or Linux
-
Warranty:
-
13months
-
Touch screen resolution:
-
4096*4096
-
Display:
-
LCD,TFT,AUO or others
-
Material Feature:
-
Anti-dust,Anti-vandal
-
Logo:
-
By customers needs
-
Touch point:
-
1,2,4,6point is available
-
General size:
-
17"
AMH wall mounted touch screen kiosk
AMK wall mounted touch screen kiosk is developed specifically for inquiry use in some public places such as Shopping Mall, hospital,hotel, bank, library, Theatre, etc.
AMH wall mounted touch screen kiosk is manufactured in Cold Roll Steel Sheets using steel plate of 1,5mm to 2.5mm which ensures the stability and rigidity of all structure.
AMH wall mounted touch screen kiosk are mainly including ticket printer touch screen kiosk, touch panel kiosk, touch lcd kiosk , touch display kiosk, touch screen kiosk 32 inch touch screen kiosk with pc touch kiosk with printer, touch kiosk with keyboard ,touch information kiosks,supermarket touch screen kiosk,etc.
Standard hardware components List o f AMH wall mounted touch screen kiosk is as following:
|
Components |
Details |
||
|
PC system |
Industrial Board |
Seavo/ Gigabyte/Advantech AIMB 562 |
|
|
CPU |
Dual core E5700/G2020, 2.8ghz; Intel Dual Core I3/I5/I7 |
||
|
RAM |
2GB /4 GB / 8GB |
||
|
HDD |
500G |
||
|
Interface |
6 RS 232 Ports;1 LTP;6 USB Ports,1 10/100M Net Port ;Integrated Net Card, Sound Card |
||
|
PC Power Supply |
HUNTKEY/Great Wall |
||
|
LCD monitor |
Screen Size |
17 inch/19inch ( optional from 8inch to 65inch) |
|
|
Brightness |
250cd/m2 |
||
|
angle |
horizontal 100°above;Vertical 80°above |
||
|
Contrast |
1000:1 |
||
|
Backlight tube life |
more than 40,000hours |
||
|
Max. resolution |
1280×1024 |
||
|
Touch screen |
Screen Size |
17/19 inch Diagonal ( optional from 8inch to 65inch) |
|
|
Resolution |
4096x4096 |
||
|
High Transparence, high precision and durability,Orientation precision< 2mm ( 0.080 inch);pure tempered glass;Single-point touch Life expectancy more 50,000,000 times |
|||
|
Digital Power Supply |
AC input voltage range |
100 240VAC |
|
|
Frequency |
50Hz to 60Hz |
||
|
Output over current protection |
110~130% |
||
|
AC input voltage range |
100 240VAC |
||
|
Frequency |
50Hz to 60Hz |
||
|
Accessories |
Wire-lan port, USB ports, speakers, fans, cables, screws, etc. |
||
|
Operation System |
Win7 or Win XP operation system without license |
||
Other Optional hardware components List of AMH wall mounted touch screen kiosk is as following:
1. A4 laser printer
2. Card dispenser
3. Metal keyboard with trackball
4. Web camera
5. Barcode scanner
6. Fingerprint reader
7. RFID card reader
