Quick Details
-
Internal dimensions:
-
6160*5560*2240mm
-
Folded state:
-
2200*5900*2480mm
-
Middle top and bottom beam:
-
80*100*T2.5mmQ235B
-
Center column:
-
150*210*T2.5mmQ235B
-
Hanging head:
-
150*210*160*T4mmQ235B
-
external roof:
-
EPS board
-
interior ceiling:
-
20# pressure gussets
-
main body:
-
75mm EPS board
-
side roof:
-
50mm EPS board
Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
CHANGTOP
-
external dimensions:
-
6320*5900*2480mm
-
Internal dimensions:
-
6160*5560*2240mm
-
Folded state:
-
2200*5900*2480mm
-
Middle top and bottom beam:
-
80*100*T2.5mmQ235B
-
Center column:
-
150*210*T2.5mmQ235B
-
Hanging head:
-
150*210*160*T4mmQ235B
-
external roof:
-
EPS board
-
interior ceiling:
-
20# pressure gussets
-
main body:
-
75mm EPS board
-
side roof:
-
50mm EPS board
Product Description
1. Simple installation, beautiful and strong, with few welding parts.
2. On-site installation: no floor required, easy disassembly and can be operated by 2-3 people, installation only takes 3-5 minutes, and it is self-contained when opened.
3. Storage cost: A set of places can be stacked and stored in multiple layers.
4. Cost of use: Compared with traditional color board houses, it saves 2/3 of temporary construction costs. Compared with other types of container houses, the cost saves 70%.
5. Features of the foldable house: Level 1 fire protection, earthquake-resistant, windproof, rainproof, can be folded repeatedly, recycled, and meets emergency living standards.
6. Use cycle: It can be folded repeatedly up to 500 times, and its service life can reach more than 10 years. Even if more than 10 construction sites are turned over in a year, the performance of the house remains reliable.
7.Application area: Folding houses are suitable for various construction sites, housing in epidemic areas, temporary residence,post-earthquake resettlement, highways, railways, construction, wind power, thermal power, photovoltaic, petroleum, rural dilapidated housing emergency, etc.
Specification
|
Basic Features
|
external dimensions(mm)
|
6320*5900*2480
|
|
|
|
Internal dimensions(mm)
|
6160*5560*2240
|
|
|
|
folded state(mm)
|
2200*5900*2480
|
|
|
Framework
|
Middle top and bottom beam
|
80*100*T2.5mmQ235B
|
|
|
|
|
|
|
|
|
Center column
|
150*210*T2.5mmQ235B
|
|
|
|
Hanging head 8
|
150*210*160*T4mmQ235B
|
|
|
|
Middle top bottom purlin
|
40*60*T1.5mmQ235B
|
|
|
|
side top frame
|
60*80 40*80*t1.5mmQ235B
|
|
|
|
Side top bottom purlin
|
40*60*t1.5mmQ235B
|
|
|
|
Folding parts for side waterproof guard
|
T2.5mmQ235B
|
|
|
|
folding hinge
|
130mm Galvanized hinge
|
|
|
|
Integral frame anti-corrosion coating
|
Electrostatic spray/straight white plastic powder
|
|
|
Box top
|
external roof
|
EPS board
|
|
|
|
interior ceiling
|
20# pressure gussets
|
|
|
Wall panel
|
main body
|
75mm EPS board
|
|
|
|
side roof
|
50mm EPS board
|
|
|
|
internal partition
|
50mm EPS board
|
|
|
Floor
|
middle floor
|
Fireproof glass magnesium floor 15mm
|
|
|
|
floor on both sides
|
bamboo flooring
|
|
|
Electrical System
|
Electrical wiring is installed in strict accordance with moisture-proof specifications, and all electrical products must comply
with CE certification. Connect the circuit according to the circuit engineering specification, indoor: 4 LED ceiling lamps, 3 five-hole single-opening sockets, 1 single-opening, 3 ten-hole sockets, 1 air-conditioning socket, 1 20A leakage protector. Voltage 220V, 50HZ |
|
|
|
|
|
|
|
|
Entry door
|
High-grade anti-theft door 1 set 970*1970mm
|
|
|
|
Window
|
4 plastic steel sliding windows (920*920mm)
|
|
|
More Types
Packing & Delivery
40HQ container can hold 2 pcs
