Quick Details
-
Brand Name:
-
reachpower
-
Model Number:
-
RSPS
-
Battery Size:
-
LifePO4
-
Place of Origin:
-
GUA
-
Weight:
-
24kg
-
The charging ratio:
-
99%
-
The discharge rate:
-
96%
-
Certification:
-
MSDS,UN38.3,CE,FCC
Quick Details
-
Storage Type:
-
dry, cool and ventilation
-
Anode Material:
-
LNO
-
Application:
-
Power Tools, Home Appliances, Solar Energy Storage Systems
-
Brand Name:
-
reachpower
-
Model Number:
-
RSPS
-
Battery Size:
-
LifePO4
-
Place of Origin:
-
GUA
-
Weight:
-
24kg
-
The charging ratio:
-
99%
-
The discharge rate:
-
96%
-
Certification:
-
MSDS,UN38.3,CE,FCC
|
Item Number
|
12.8V100Ah
|
|
Nominal voltage [V]
|
12.8
|
|
Nominal capacity [Ah]
|
100
|
|
Total energy [KWh]
|
1.28
|
|
Product dimension [W*D*H]
|
320*190*160 mm
|
|
Product weight
|
10±0.5 Kg
|
|
Max. charging current [A]
|
150
|
|
Charge Mode
|
@0.2C(A) to 14.6V ,then @14.6V till charge current<0.05C(A) (CC,CV)
|
|
Charging voltage [V] Max. discharging current [A]
|
14.6 150
|
|
End of discharge voltage [V] Protection class
|
11.2 IP65
|
|
Operating humidity
|
0-95 %RH (No condensing)
|
|
Operating temperature range
|
Charge: 0 ~ +50 °C Discharge: -20 ~ +55 °C
|
|
Storage temperature range
|
-20 ~ +60 °C / -4 ~+140°F
|
|
Communication interface
|
/
|
|
BMS Functions Protection
|
Cell Voltage/Current Balance, Temperature, MOSFETS Over voltage , Low voltage , Over current,
|
|
loiecon Certification
|
Over Temperature, Low Temperature Short circuit UN38.3, CE
|
