- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
RZF
-
Place of Origin:
-
Hebei, China
-
Panel Dimensions:
-
2056*1140*35mm
-
Front Glass:
-
High transmission, low iron tempered glass
-
Panel Efficiency:
-
19.6%
-
Certificate:
-
TUV, CE, ISO
-
Frame color:
-
Silver, Silver White, black, gold or customized
-
Quality of cell:
-
Grade A
-
OEM or ODM:
-
Available
-
Cell:
-
PID resistant
-
Output:
-
High power output
-
Junction box:
-
IP67, Bypass diodes protection
-
Test:
-
Salt mist and ammonia resistance test
Quick Details
-
Cell size:
-
156mm*52mm
-
Type:
-
PERC, Half Cell
-
Warranty:
-
25 years warranty
-
Brand Name:
-
RZF
-
Place of Origin:
-
Hebei, China
-
Panel Dimensions:
-
2056*1140*35mm
-
Front Glass:
-
High transmission, low iron tempered glass
-
Panel Efficiency:
-
19.6%
-
Certificate:
-
TUV, CE, ISO
-
Frame color:
-
Silver, Silver White, black, gold or customized
-
Quality of cell:
-
Grade A
-
OEM or ODM:
-
Available
-
Cell:
-
PID resistant
-
Output:
-
High power output
-
Junction box:
-
IP67, Bypass diodes protection
-
Test:
-
Salt mist and ammonia resistance test
|
MECHNICAL CHARACTERISTICS
|
|
|
|
Frame Material
|
Anodized Aluminium Alloy
|
|
|
Front Glass
|
Low iron tempered glass
|
|
|
Cell encapsulant
|
EVA
|
|
|
Junction Box
|
IP67
|
|
|
Cables
|
2.5mm²
|
|
|
Connector
|
MC4
|
|
|
Max wind load
|
2400Pa
|
|
|
Max snow load
|
5400Pa
|
|
|
TEMPERATURE COEFFICIENT
|
|
|
|
NOCT
|
47℃(±2℃)
|
|
|
Temperature Coefficient of Pmax
|
-0.45%/℃
|
|
|
Temperature Coefficient of Voc
|
-0.35%/℃
|
|
|
Temperature Coefficient of Isc
|
0.05%/℃
|
|
|
Operating Temperature
|
-40℃～+85℃
|
|
|
ELECTRONICAL CHARACTERISTICS
|
|
|
|
|||
|
Module Type
|
OS-P36-40
|
OS-P36-50
|
OS-P36-60
|
|||
|
Maximum Power(Pmax)
|
40W
|
50W
|
60W
|
|||
|
Maximum Power Voltage(Vmp)
|
18.0V
|
18.0V
|
18.0V
|
|||
|
Maximum Power Current(Imp)
|
2.22A
|
2.78A
|
3.33A
|
|||
|
Open Circuit Voltage(Voc)
|
21.8V
|
21.8V
|
21.8V
|
|||
|
Short Circuit Current(Isc)
|
2.35A
|
2.95A
|
3.53A
|
|||
|
Number of cells
|
36(4*9)
|
36(4*9)
|
36(2*18)
|
|||
|
Size of Cells(mm)
|
156*39
|
156*52
|
156*62.4
|
|||
|
Dimensions
|
420*670*25
|
540*670*30
|
650*670*30
|
|||
|
Power of Tolerance
|
±3%
|
|
|
|||
|
Maximum System Voltage
|
1000VDC
|
|
|
|||
|
|
|
|
|
|||
