Quick Details
-
Voltage:
-
220/380
-
Power:
-
0.75-4kw
-
Dimension(L*W*H):
-
1230*1700*2190
-
Weight (KG):
-
290
-
Weight:
-
290-1200kg
-
Rated Capacity (kg):
-
20-150
-
Speed of Roller (r/min):
-
29-35
-
Heating:
-
Steam, electric , gas
-
Power of Motor(kw):
-
0.75-4
-
Power of Draught Fan (kw):
-
0.75-4.4
-
Steam Pressure(Mpa):
-
0.4-0.6
-
Certification:
-
ISO & CE
-
Usage:
-
Fabric,clothes drying
-
Weight (kg):
-
600
Quick Details
-
Type:
-
Drying Oven
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Taifeng
-
Voltage:
-
220/380
-
Power:
-
0.75-4kw
-
Dimension(L*W*H):
-
1230*1700*2190
-
Weight (KG):
-
290
-
Weight:
-
290-1200kg
-
Rated Capacity (kg):
-
20-150
-
Speed of Roller (r/min):
-
29-35
-
Heating:
-
Steam, electric , gas
-
Power of Motor(kw):
-
0.75-4
-
Power of Draught Fan (kw):
-
0.75-4.4
-
Steam Pressure(Mpa):
-
0.4-0.6
-
Certification:
-
ISO & CE
-
Usage:
-
Fabric,clothes drying
-
Weight (kg):
-
600
|
Model
|
HG-20
|
HG-30
|
HG-50
|
HG-100
|
HG-120
|
HG-150
|
|
Rated Capacity (kg)
|
20
|
30
|
50
|
100
|
120
|
150
|
|
Drum Size (mm)
|
φ800×500
|
φ900×800
|
φ1080×1120
|
φ1470×1000
|
φ1470×1220
|
φ1600×1350
|
|
Drum Speed (RPM)
|
32-35
|
30-33
|
30-33
|
30-33
|
30-33
|
29-31
|
|
Steam Pressure (MPa)
|
0.4-0.6
|
0.4-0.6
|
0.4-0.6
|
0.4-0.6
|
0.4-0.6
|
0.4-0.6
|
|
Electric Heating Power (kw)
|
12
|
15
|
24
|
48
|
/
|
/
|
|
Motor Power (kw)
|
0.75
|
1.1
|
1.5
|
2.2
|
3
|
3
|
|
Fan Power (kw)
|
0.75
|
0.75
|
1.1
|
2×1.5
|
2×2.2
|
2×2.2
|
|
Dimension (mm)
|
950×980 ×1750
|
1000×1300×1890
|
1230×1700×2190
|
1650×1710 ×2450
|
1650×1960 ×2550
|
1820×2120 ×2560
|
|
Weight (kg)
|
290
|
580
|
600
|
800
|
900
|
1200
|
low energy consumption, low rate of wear, low noise
safe & reliable
automatic temperature control
high quality of stainless steel drum
computer control
Capacity can be chosen from15kg-150kg
can be used in hotels, inns, hospitals, laundering and dyeing shops, knitting mills, passenger transportation sections,
troops, industrials mining enterprises etc. They are ideal machines for drying cotton, silk, chemical fiber goods etc.
Large lint collecting screen with large air vanes to ensure no air-ducting blockage and smooth air flow all the time
safe & reliable
automatic temperature control
high quality of stainless steel drum
computer control
Capacity can be chosen from15kg-150kg
can be used in hotels, inns, hospitals, laundering and dyeing shops, knitting mills, passenger transportation sections,
troops, industrials mining enterprises etc. They are ideal machines for drying cotton, silk, chemical fiber goods etc.
Large lint collecting screen with large air vanes to ensure no air-ducting blockage and smooth air flow all the time
