Quick Details
-
Model Number:
-
308
-
Power supply:
-
USB
-
Certificate:
-
CE ISO
-
Product name:
-
nebulizer
-
Material:
-
ABS
-
Warranty:
-
3 Years
-
Function:
-
Health Care
-
Application:
-
Home Care
Quick Details
-
Properties:
-
Anatomy Appliances
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SZMIQU
-
Model Number:
-
308
-
Power supply:
-
USB
-
Certificate:
-
CE ISO
-
Product name:
-
nebulizer
-
Material:
-
ABS
-
Warranty:
-
3 Years
-
Function:
-
Health Care
-
Application:
-
Home Care
Product Description
Product Description
|
Operation Environment
|
Temperature: 5 40 .
|
||||||||||||
|
Relative humidity: 80%.
|
|||||||||||||
|
Atmosphere pressure: 80.0kPa 106.0kPa
|
|||||||||||||
|
Spray rate
|
The spray rate should be 0.2mL/min.
|
||||||||||||
|
Air flow volume
|
Compressed air flow of compression pump: 8L/min.
|
||||||||||||
|
Pressure range
|
1. Under normal working conditions, the pressure range of device is 60kPa 130kPa.
2. When the pipeline blockage occurs etc. in the device, the pressure produced by the device will not break in the range of 130kPa ~ 400kPa. |
||||||||||||
|
Residual liquid volume
|
0.7mL
|
||||||||||||
|
Machine noise
|
Noise of machine in normal operation: 65dB (frequency-weighting characteristic A).
|
||||||||||||
|
Continuous working hours
|
When the device works continuously for more than 4 hours under normal temperature and AC power supply, it should be able to work
normally. |
||||||||||||
|
Enclosure leakage current
|
Normal condition 0.1mA; Single fault condition 0.5mA.
|
||||||||||||
|
Patient leakage current
|
Nomal condition 0.1mA; Single fault condition 0.5mA.
|
||||||||||||
|
Droplet particle size
|
1um-5um
|
||||||||||||
Packing&Shipping
Packing&Shipping
465*363*495mm, 8 pieces, 14kg GW, NW:10KG
