Pre-Sales
*We own pre-sales , selling and after sales service teams , to ensure provide professional and integration service for each project .
Selling
*We have engineer with rich project experience , who are available to prospect customer's site, formulate layout and confirm the feasibility of program, final participate the installation and system testing.
After-Sales
*7X24hours after-sales service
-Service phone line keep 24 hours unblocked
-All emails will get response within 10 hours
-Any needed machine parts can be supplied with professional guiding and ordinary.
-Collect after-sale-service feedback from customer, keep improving.
*we have rich experience after sale staff who have the ability of handling emergency situation, that can ensure machine normal working and customer's production go smoothly.
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
JEWEL
-
Weight:
-
9000 KG
-
Dimension(L*W*H):
-
2100*1200*2100
-
application:
-
specially designed for tyre
-
door opening:
-
hydraulic door opening
-
cylinder:
-
double cylinder
-
operation mode:
-
manual valve
-
Factory sell directly:
-
Yes
-
Capability:
-
4-5bales/hr
-
Bale size:
-
2000*1200*(700-1250)
-
Name:
-
CE Certification Car Tyre Baling Press Factory Directly Sale
-
Bale weight:
-
1300-2000
Quick Details
-
Voltage:
-
(200-480)V(customizable)
-
Power:
-
30KW
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
JEWEL
-
Weight:
-
9000 KG
-
Dimension(L*W*H):
-
2100*1200*2100
-
application:
-
specially designed for tyre
-
door opening:
-
hydraulic door opening
-
cylinder:
-
double cylinder
-
operation mode:
-
manual valve
-
Factory sell directly:
-
Yes
-
Capability:
-
4-5bales/hr
-
Bale size:
-
2000*1200*(700-1250)
-
Name:
-
CE Certification Car Tyre Baling Press Factory Directly Sale
-
Bale weight:
-
1300-2000
Product Description
* The machine is special design for the tires.
* Hydraulic door opening, double cylinder,has manual valve and electric valve operation.
* Suitable for compressing automobile tires, waste rubber, etc, rubber raw material products.
* Adopt England brand sealing parts, improve the life time of oil cylinder.
* Oil pipe joint adopts conical without gasket form, no oil leakage phenomenon.
* Adopt Taiwan brand superposition type valve group.
* Adopt connect motor with pump directly, to ensure 100% concentricity, and extend use life of pump.
* OT100/OT120 is integrated type machine, open door by manual.
* OT150/OT180 is split type machine, open door by hydraulic.
* Hydraulic door opening, double cylinder,has manual valve and electric valve operation.
* Suitable for compressing automobile tires, waste rubber, etc, rubber raw material products.
* Adopt England brand sealing parts, improve the life time of oil cylinder.
* Oil pipe joint adopts conical without gasket form, no oil leakage phenomenon.
* Adopt Taiwan brand superposition type valve group.
* Adopt connect motor with pump directly, to ensure 100% concentricity, and extend use life of pump.
* OT100/OT120 is integrated type machine, open door by manual.
* OT150/OT180 is split type machine, open door by hydraulic.
|
Model
|
JP-OT100
|
JP-OT120
|
JP-OT150
|
|
Hydraulic power
|
100Ton
|
120Ton
|
150Ton
|
|
Packaging size（L*W*H）
|
1400*700*(700-1100) mm
|
1400*700*(700-1100) mm
|
1800*1000*(700-1250) mm
|
|
Feed opening size（L*H）
|
1400*600mm
|
1400*600mm
|
1800*750mm
|
|
Chamber Size （L*W*H）
|
1400*700*1700 mm
|
1400*700*1700 mm
|
1800*1000*2100 mm
|
|
Capability
|
5-6 bales/hour
|
5-6 bales/hour
|
4-5 bales/hour
|
|
Bale weight
|
400-600Kg
|
500-700Kg
|
1000-1500Kg
|
|
Voltage
|
can be customized
|
can be customized
|
can be customized
|
|
Power
|
15KW/20HP
|
15KW/20HP
|
22KW/30HP
|
|
Weight
|
3500Kg
|
4000Kg
|
7000Kg
|
Product Picture
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profie
Our company was established in 1995,we have 25 years manufacturing experience until now,our machines have been exported to more than 120 countries all over the world.Our plant is located in Nantong city,Jiangsu province,2 hours driving from Shanghai.Our factory covers an area of 33300㎡,welcome to visit!
