Quick Details
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
HUGO 1t wire rope sling
-
Model Number:
-
web sling
-
1t wire rope sling Name:
-
Approved polyester webbing lifting slings flat 1t wire rope sling
-
Temperature demand:
-
-40℃-100℃
-
1t wire rope sling Function:
-
lashing tie down
-
Working capacity:
-
1 ton
-
Breaking capacity:
-
6000kg
-
1t wire rope sling Length:
-
10 M
-
1t wire rope sling Loading port:
-
Shanghai
-
Certification:
-
GS
Quick Details
-
Type:
-
Webbing Sling
-
Shape:
-
Flat
-
Warranty:
-
1 years
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
HUGO 1t wire rope sling
-
Model Number:
-
web sling
-
1t wire rope sling Name:
-
Approved polyester webbing lifting slings flat 1t wire rope sling
-
Temperature demand:
-
-40℃-100℃
-
1t wire rope sling Function:
-
lashing tie down
-
Working capacity:
-
1 ton
-
Breaking capacity:
-
6000kg
-
1t wire rope sling Length:
-
10 M
-
1t wire rope sling Loading port:
-
Shanghai
-
Certification:
-
GS
Polyester Lifting Webbing Sling/Crane Lifting Belt
Introduction of Construction material polyester flat woven webbing sling
The maximum load of flat web slings ranges from 0-30 ton. The length ranges from 1-100 meters. The flt web slings are made of 100%PES, and can enhance the strength of web slings by using intensive eyes or mental accessories at both ends.
Advantages of Construction material polyester flat woven webbing sling
1.The product can be devided into single layer and multi-layer, and can sew in many ways.
2.The siza can follow the customer's requirements.
3.Wide bearing surface, which can reduce the pressure of surface load.
4.Smooth surface, which won't hurt the lifted objects.
5.High strength-to-weight ratio.
6.It can add anti-wear protective sleeve&anti-cut protective cover.
7.It has unique label, and use international standard colours to distanguish the bearing capacity.
8.Easy to carry and soft in texture.
9.The product has experienced PU surface hardening treatment, which enhance the wear resistance.
10.Comply with European standard:EN1492-1:2000.
Parameters of Construction material polyester flat woven webbing sling
|
Model |
Minimum breaking Load(kg) | Rated Load(kg) | Vertical Lift P=1(kg) |
45 Degree Angle Lift P=1.8(kg) |
90DegreeAngle Lift P=1.4(kg) |
|
EB-B-01 |
6000 | 1000 | 1000 | 1800 | 1400 |
| EB-B-02 | 12000 | 2000 | 2000 | 6900 | 2800 |
| EB-B-03 | 18000 | 3000 | 3000 | 5400 | 4200 |
| EB-B-04 | 24000 | 4000 | 4000 | 7200 | 5600 |
| EB-B-05 | 30000 | 5000 | 5000 | 9000 | 7000 |
| EB-B-06 | 36000 | 6000 | 6000 | 10800 | 8400 |
| EB-B-08 | 48000 | 8000 | 8000 | 14000 | 11200 |
| EB-B-10 | 60000 | 10000 | 10000 | 18000 | 14000 |
| EB-B-12 | 72000 | 12000 | 12000 | 21600 | 16800 |
| EB-B-20 | 120000 | 20000 | 20000 | 36000 | 28000 |
| EB-B-30 | 180000 | 30000 | 30000 | 54000 | 42000 |
