Quick Details
-
Panel Size:
-
34 inch
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
HBY-T340P
-
Pixel Pitch:
-
0.05, 0.05
-
Product name:
-
Stretched LCD Bar Screen
-
Certificate:
-
CE/CCC/FCC/ROHS
-
Installation:
-
Wall mounted or hanging
-
OSD language:
-
Chinese/English
-
Touch screen:
-
Option Multi Touchscreen 10 Points
-
Resolution:
-
1920*540
-
Warranty:
-
1 Year
-
Viewing Angle:
-
89/89/89/89
-
Response Time:
-
5ms
Quick Details
-
Application:
-
Indoor
-
Brand Name:
-
OEM ODM
-
Color:
-
Black
-
Panel Size:
-
34 inch
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
HBY-T340P
-
Pixel Pitch:
-
0.05, 0.05
-
Product name:
-
Stretched LCD Bar Screen
-
Certificate:
-
CE/CCC/FCC/ROHS
-
Installation:
-
Wall mounted or hanging
-
OSD language:
-
Chinese/English
-
Touch screen:
-
Option Multi Touchscreen 10 Points
-
Resolution:
-
1920*540
-
Warranty:
-
1 Year
-
Viewing Angle:
-
89/89/89/89
-
Response Time:
-
5ms
♦Mohs level 7 high-transparency explosion-proof tempered glass, as solid as a rock;
♦Military-grade switching power supply, wide voltage input, high temperature resistance, stable and reliable;
♦The body is made of cold-rolled steel, car paint process, anti-rust and anti-static, beautiful and generous;
♦The system configuration, touch screen, and supporting software can be purchased on demand, with flexible matching.
Basic Parameters(Touch function optional, accept customized size.)
| LCD Panel |
Size |
34 Inch More sizes for choosing (28.6/12.2/19.5/28/24/18.9/35.1/36.8/37.6/37/43.9/43/48.1/48.8/49.5/60/68.2/69.3/88) |
| Resolution | 1920*540 | |
| Brightness | 500cd/m 2 (accept customized) | |
| Viewing Angel | 89/89/89/89 | |
| Contrast Ratio | 1100:1 | |
| Display Area |
885mm*50mm |
|
| Power Supply | Input voltage |
AC 90V-264V 60/50Hz |
| Power | <30W | |
| Audio | Built-in speaker | 8Ω5W*2 |
| Conditions | Working temperature | 0-45C o |
| Storage temperature |
-10-60C o |
|
|
Working humidity |
10%-80% | |
| Storage humidity | 10%-90% |
Touch funciton for the lcd streched bar screen.
| Touch Function (Optional) | Parameter | Infrared Touch | PCAP Touch |
| Touch Technology |
Non-contact infrared sensor |
Projected capacitance (G+F) | |
| Resolution | 4096*4096 | 4096*4096 | |
| Accurancy | 2mm | 1.5mm | |
| Multi Touch | 10 points touch | 10 points touch | |
| Effectively identify size | 6mm | 1mm | |
| communication method | USB Free drive | USB Free drive |
