Quick Details
-
Production Capacity:
-
240 t/h
-
Power:
-
73.5kw
-
Place of Origin:
-
Jiangsu, China
-
Dimension(L*W*H):
-
6680*3000*4000mm
-
Driving speed:
-
20m/min
-
Maximum paving speed:
-
18m/min
Quick Details
-
Max. Paving Thickness:
-
350mm
-
Weight:
-
11000 kg
-
Engine Brand:
-
famous brand
-
Production Capacity:
-
240 t/h
-
Power:
-
73.5kw
-
Place of Origin:
-
Jiangsu, China
-
Dimension(L*W*H):
-
6680*3000*4000mm
-
Driving speed:
-
20m/min
-
Maximum paving speed:
-
18m/min
Asphalt
Concrete Paver
RP453L
Contact Way
Product Overview
—The functional console is modularized, the control system of the main switch gear is used, the automatic leveling device is used, the transverse gradient is within 0.02%, wet multi-disc brakes are used for driving and Parking brake, the whole machine is safe and reliable, and the material-discharging blades are made of highly wear-resistant Cr-Ni-based materials to extend the service life.
Product Paramenters
|
Item
|
RP453L
|
|
dimension
|
5690×2070×3590mm
|
|
Weight
|
11t
|
|
Driving speed
|
0-20m/min
|
|
Basic pave width
|
1.8-3.4m
|
|
Maximum pave width
|
4.5m
|
|
Maximum layer thickness
|
260mm
|
|
Maximum paving speed
|
18m/min
|
|
Hopper capacity
|
12t
|
|
Maximum laydown rate
|
240t/h
|
|
Rate power
|
73.5/2000 kw/rpm
|
