Quick Details
-
Mounting Type:
-
Threaded Hidden Connection
-
Description:
-
intelligent non-contact sensor switch, Inductive Sensor
-
Model Number:
-
XKC-KE200
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Xingkechuang
-
Theory:
-
Photoelectric Sensor
-
Output:
-
High and low level signal output
-
Sensing distance:
-
up to 4 meters
-
Operating Voltage:
-
DC 5V~24V
-
Sensing angle:
-
30-40°cone angle
-
Output type:
-
High and low, NPN, Relay,UART
-
Application:
-
Home Automation,Lights,Alarm Security etc.
Quick Details
-
Usage:
-
Proximity Sensor
-
Series:
-
XKC-KE200 Active Infrared Sensors
-
Features:
-
Photoelectric Sensor, Proximity Sensor
-
Mounting Type:
-
Threaded Hidden Connection
-
Description:
-
intelligent non-contact sensor switch, Inductive Sensor
-
Model Number:
-
XKC-KE200
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Xingkechuang
-
Theory:
-
Photoelectric Sensor
-
Output:
-
High and low level signal output
-
Sensing distance:
-
up to 4 meters
-
Operating Voltage:
-
DC 5V~24V
-
Sensing angle:
-
30-40°cone angle
-
Output type:
-
High and low, NPN, Relay,UART
-
Application:
-
Home Automation,Lights,Alarm Security etc.
Product Description
|
Operating Voltage
|
DC 5V
~
24V
|
| Sensing distance | up to 4meters |
1st. Overview
XKC-KE200 is an intelligent non-contact sensor switch. The sensor uses the principle of diffuse reflection of infrared
light on the object. When a person or object enters the sensing range directly in front of the sensor, the sensor immediately
judges that there is a sensor, thereby controlling the output signal ; After the person or object leaves the sensing range, it is
immediately judged that there is no sensing, and the output signal is released to achieve the purpose of intelligent control.
2nd.Product Features
Can be used for: security alarm, sensor light, smart trash can, mirror light box, advertising machine, shoe polisher, sensor
water dispenser, vending machine, faucet, shower head and other functions. It integrates infrared emission, reception, and
intelligent control, with stable and reliable performance.
3rd.Technical Parameters
