DD45 pile hammer

Features

1. Working based on two stroke internal combustion diesel engine principle
2. Soft soil starting, cold starting very well
3. Simple structure, convenient for maint ain
4. Combine with our company walking pile frame, and reach a good performance
5. Widely used for metal stake, concrete stake, infuse stake and tamp stake
6. App l ication: Port, wharf, airport. Super high way, railroad. High fou n dation building

Characteristic

• Compared with other pile hammer, this rod diesel pile hammer is not only simple but also practical, with simplified structure, being easy to operate, maintain and start up well.

• It is convenient for onshore and offshore piling project. This kind diesel pile hammer can be mounted to crane, excavator, pile driver, etc.

  Specifications

  		DD18	DD25	DD35	DD45	DD55	DD65	DD75	DD85	DD95	DD103
  Cylinder weight	kg	1800	2500	3200	4000	5300	6300	7300	8300	9300	10300
  Max cylinder stroke	mm	2100	2300	2800	3000	3000	3000	3000	3000	3000	3000
  Frekuency	per/min	45-50	42-50	40-50	30-50	30-50	30-50	30-50	30-50	35-50	35-50
  Max. Energy	kJ	37	58	88	120	158	190	220	248	284	310
  Oil consumption	ltr/hour	6.9	10	12	14	16	18	19	20	22	24
  Cylinder bore	mm	290	370	410	450	510	550	590	600	650	650
  Reduction ratio		22	22	22	22	22	22	22	22	22	22
  Hammer mass	ton	3.125	4.2	5.35	7.32	9.8	11.5	13	14.5	16	17.5
  Guide type		Chanel pipe	Chanel pipe	Chanel pipe	Pipe	Pipe	Pipe	Pipe	Pipe	Pipe	Pipe
  Guide distance	mm	360/330	360/330	360/330	360/330	360	360	600	600	600	600
