Quick Details
-
Brand Name:
-
OCEANA
-
Voltage:
-
380V
-
Power:
-
132kw
-
Dimension(L*W*H):
-
4100*2350*1850
-
Weight:
-
1000 kg
-
Warranty:
-
12 months
-
Name1:
-
machine for concrete jacking pipe
-
Name2:
-
equipment for concrete jacking pipe
-
piping material:
-
CONCRETE
Quick Details
-
Pipe Material:
-
CONCRETE
-
Production Capacity:
-
80 pipe per day
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
OCEANA
-
Voltage:
-
380V
-
Power:
-
132kw
-
Dimension(L*W*H):
-
4100*2350*1850
-
Weight:
-
1000 kg
-
Warranty:
-
12 months
-
Name1:
-
machine for concrete jacking pipe
-
Name2:
-
equipment for concrete jacking pipe
-
piping material:
-
CONCRETE
Our XG Series pipe making machine is one of the most popular pipe making machines around the market. Using Sand, Gravels, Fly ash, cement and water as the raw material, mixing them to high quality concrete, then we can conveyor the half-dry concrete with the concrete feeder to the mould, the mould together with Concrete will rotate at high speed , the concrete will become solid and high strength with the Centrifugal force and the roller force. After several hours curing, the standard pipes will come out.
During the production, you will need:
1. Concrete Mixer and Batching machine
2. Wire Cage welding machine
3. Roller Suspension pipe making machine
4. Steel Pipe Mould
5.Concrete feeder
6.Gantry Crane
Concrete pipe making machine of Suspension Roller type with XG2500
Technical parameter:
1) Pipe diameter: 200-2, 400mm
2) Hang axis diameter: 144-216mm
3) Product length: 1000- 3,000mm
4) Power: 15- 132kW
5) Hang axis speed: 62-618rpm
6) Machine size: 4, 100 x 2, 350 x 1,850mm
7) There have different capacity of making machines
if you interested, welcome to contact with us for more details
....regards kimi
