Quick Details
-
Model Number:
-
laminated glass
-
Product name:
-
Clear Laminated Glass
-
Glass color:
-
Clear, Extra Clear and orther color
-
Size:
-
300x300mm, 3300x2140mm, 1830x2140mm, etc
-
Material:
-
glass and PVB film
-
Thickness:
-
6.38mm, 8.38mm, 10.38mm, 12.38mm, 6.76mm, 8.76mm, etc
-
Edge:
-
Flat edge,grind edge,fine polished edge,bevelled edge
-
Color:
-
clear,and orther color
-
PVB Thickness:
-
0.38mm,0.76mm,1.14mm,1.52mm,1.9mm
-
Certificate:
-
CE, ISO, CCC, BS6202
Quick Details
-
Application:
-
Office Building
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
THRIKING
-
Model Number:
-
laminated glass
-
Product name:
-
Clear Laminated Glass
-
Glass color:
-
Clear, Extra Clear and orther color
-
Size:
-
300x300mm, 3300x2140mm, 1830x2140mm, etc
-
Material:
-
glass and PVB film
-
Thickness:
-
6.38mm, 8.38mm, 10.38mm, 12.38mm, 6.76mm, 8.76mm, etc
-
Edge:
-
Flat edge,grind edge,fine polished edge,bevelled edge
-
Color:
-
clear,and orther color
-
PVB Thickness:
-
0.38mm,0.76mm,1.14mm,1.52mm,1.9mm
-
Certificate:
-
CE, ISO, CCC, BS6202
Clear tempered Laminated Glass Price
Related Glass
Specification of Clear Laminated Glas
|
Thickness of tempered laminated glass |
3+0.38+3mm,4+0.38+4mm,5+0.38+5mm,6+0.38+6mm, 3+0.76+3mm,4+0.76+4mm, 5+0.76+5mm, 6+0.76+6mm etc, Could be produced as per request. |
|
Raw Materials |
Qualified float glass, low-e glass, tempered, frosted, etc. |
|
Corner |
natural corner, grind corner, round corner with fine polished |
|
PVB color |
Clear, Green, Blue, Bronze, Grey, Milk white etc. |
|
Glass Color |
Clear, Extra Clear, French Green, Dark Green, Ford Blue, Dark Blue, Bronze, Euro Grey etc. available with reflective glass also |
Description of Clear Laminated Glass
Yantai thriking LAMINATED GLASS is made by good quality adhesive interlayer and advanced bond
technology. Laminated Glass is a kind of glass made up of two or more sheets of top quality glass bond
ed together with a polyvinyl butyral (PVB) interlayer. After the PVB interlayer has been placed between
the glass sheets, the whole assembly is subjected to heat and pressure. This makes the complete
adhesion of the vinyl and the glass. In the event of breakage, the glass fragments remain bonded to
the plastic interlayer.
Advantage of Clear Laminated Glass
1) Extremely high safety: The PVB interlayer withstands penetration from impact. Even if the glass
cracks, splinters will adhere to the interlayer and not scatter. In comparison with other kinds of glass,
laminated glass has much higher strengt-h to resist shock, burglary, burst and bullets.
2) Energysaving building materials: PVB interlayer impedes the transmission of solar heat and
reduces cooling loads.
3) Create aesthetic sense to buildings: Laminated glass with a tinted interlayer will beautify the buildings
and harmonize their appearances with surrounding views which meet the demand of architects.
4) Sound control: PVB interlayer is an effective absorber of sound.
5) Ultraviolet screening: The interlayer filters out ultraviolet rays and prevents the furniture and curtains
from fading effect.
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
