Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Vility
-
Dimensions(L*W*H):
-
90*45*33cm
-
Weight:
-
8 KG
-
Certification:
-
ce
-
Application:
-
Print T Shirt
-
Type:
-
Silk Screen Printing Machine
-
Product name:
-
Screen Printing Press
-
Color:
-
1 Color
-
Printing type:
-
1time 1 Color
-
Station:
-
1Station
-
Keywords:
-
Silk Screen Printer Machine
-
MOQ:
-
5 Pcs
-
Brand:
-
Vility
Quick Details
-
Condition:
-
New
-
Color & Page:
-
single color
-
Voltage:
-
220V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Vility
-
Dimensions(L*W*H):
-
90*45*33cm
-
Weight:
-
8 KG
-
Certification:
-
ce
-
Application:
-
Print T Shirt
-
Type:
-
Silk Screen Printing Machine
-
Product name:
-
Screen Printing Press
-
Color:
-
1 Color
-
Printing type:
-
1time 1 Color
-
Station:
-
1Station
-
Keywords:
-
Silk Screen Printer Machine
-
MOQ:
-
5 Pcs
-
Brand:
-
Vility
Product Category
Product Description
Roll to roll CCD alignment screen printing machine
Roll to roll CCD alignment screen printing machine
consists of three main parts: automatic feeding machine, CCD precision printing machine and automatic oven.
The whole production line can be controlled by one person, no pause in the printing process, high precision.
The alignment error shall not exceed 0.02mm.
This machine is widely used in FPC,PET, PVC, varies of label,transfer paper (film), floor heating film, geothermal film, electro thermal film, color paper, film, name plate, flexible circuit board, mobile phone keys, Membrane switch, trademark printing, scratch CARDS, self-adhesive stickers, paper, ribbon, aluminum foil and copper foil this roll material silk screen printing.
High precision CCD vision alignment with 0.02mm error. Suitable for all flexible roll material printing.
Sample picture after printing
Related Products
Specification
| Name | Roll to roll CCD screen printing machine |
| Custom | Yes |
| Usage | flexible roll material printing |
| Advantage | High Efficiency |
| Control system | PLC |
| Printing precision | 0.02mm |
| Packing | Wooden Package |
| Power | 40KW |
| Volatge | 380V/50Hz |
| Registration method | CCD visual alignment |
| Product Keywords | roll to roll pvc film silk screen printing machine,flat bed screen printing machine |
The above parameters are for our standard
Roll to roll CCD alignment screen printing machine
. If this specification meets your production requirements you can place your order directly and we will ship it to you immediately.
If you need to customise some of these parameters, we will improve them for you to ensure that the product meets your requirements exactly. As soon as the machine has been commissioned, we will deliver it to you.
If you need to customise some of these parameters, we will improve them for you to ensure that the product meets your requirements exactly. As soon as the machine has been commissioned, we will deliver it to you.
Product Overviews
The Feeder features:
(2) feeding speed, time, can adjust at will.
(3) the feeding starting speed, can adjust at will, start frequency starting from 0 up to run slowly, avoid the start too fast, cause the material surface scratches.
(4) equipped with an automatic protective device.
Main machine feature---screen printing machine
(1) Multicolor printing, automatic photocell eye counterpoint, computer control, automatic detection color code, if have any abnormal , it will stop automatic.
(2)Using numerical control motor, printing speed, return to the ink speed can be set in a random block.
(2)Using numerical control motor, printing speed, return to the ink speed can be set in a random block.
(3) Using numericalcontrol motor, printing distance, return to the ink distance can be set in a random data.
(4)Automatic computing printing, andcalculate the qty, and printing can be set automatically stop.
(5)photoelectric control feeding and discharging to avoid thesurface damage of substrates, can improve the printing quality.
(6)Setting of printing speed and cycle run can be controlled via touch panel.
New Technology (CCD automatic XYθ rotary alignment printing)
1.CCD automatic XYθ rotation alignment adjustment .
2.Quick screen changer, high production efficiency .
3.CCD high precision alignment ±0.02mm .
4.No pause at halfway, electric eye cursor .
5.No requirements for the accuracy of pulling materials .
6.Provincialworkers, one person can take care of 3 machines.
Main machine feature-The dryer features:
(1) Circulating hot air drying, temperature adjustable, automatic winding.
(2) The oven cover an small area, 32-60 meters length, which can realize low temperature drying, ensure printed material no shrinkage deformation, multicolor printing.
