Quick Details
-
Range of Spindle Speed(r.p.m):
-
70 - 320 r.p.m
-
Max. Turned Length (mm):
-
1000 mm
-
Year:
-
2021
-
Place of Origin:
-
China
-
Brand Name:
-
AMCO
-
Model Number:
-
C9372
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
1000*860*1300
-
Weight (KG):
-
300 KG
-
Marketing Type:
-
New Product 2021
-
CNC or Not:
-
Normal
-
Power (kW):
-
0.55
-
Max. Swing Diameter (mm):
-
50 mm
-
After-sales Service Provided:
-
Online support
-
After Warranty Service:
-
Video technical support
-
Certification:
-
ISO9001
Quick Details
-
Max. Length of Workpiece (mm):
-
Other
-
Machining Capacity:
-
Medium Duty
-
Spindle Bore(mm):
-
229 m'm
-
Range of Spindle Speed(r.p.m):
-
70 - 320 r.p.m
-
Max. Turned Length (mm):
-
1000 mm
-
Year:
-
2021
-
Place of Origin:
-
China
-
Brand Name:
-
AMCO
-
Model Number:
-
C9372
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
1000*860*1300
-
Weight (KG):
-
300 KG
-
Marketing Type:
-
New Product 2021
-
CNC or Not:
-
Normal
-
Power (kW):
-
0.55
-
Max. Swing Diameter (mm):
-
50 mm
-
After-sales Service Provided:
-
Online support
-
After Warranty Service:
-
Video technical support
-
Certification:
-
ISO9001
* Quickly, accurately and efficiently to cutting rotor;
* Fast and slow setting allow cutting rotor;
* Quick, accurately and efficiently to cutting drum;
* Finitely adjustably setting allow cutting drum;
* Three kinds of speed to choice for spindle speed;
* Fully equipped adapter package.
* A convenient design allows to quickly change from rotor to drum;
* Position of stop make the lathe stop automatic after the cutting
|
Model |
C9350 |
C9372 |
|
Spindle Travel |
175mm |
/ |
|
Spindle Speed |
70, 80, 118rpm |
70-320 rpm |
|
Spindle Feed Speed |
Min 0.05mm/rev |
|
|
Max 0.5mm/rev |
|
|
|
Cross Feed Speed |
Min 0.05mm/rev |
Rotor and drum feed rates 0-0.66mm |
|
Max 0.5mm/rev |
|
|
|
Handwheel Graduations |
0.05mm |
|
|
Rotor Diameter |
180-381mm |
102-610mm |
|
Rotor Thickness |
48mm |
73mm |
|
rum Diameter |
152-711mm |
152-711mm |
|
Drum Depth |
175mm |
229mm |
|
Motor |
1PH 110V/220V 50/60HZ , 1PH 110/220V 50/60HZ |
|
|
Gross Weight |
290kg |
300kg |
|
Dimension |
970x920x1140mm |
1000x860x1300mm |
1. Who are we?
We are based in Shaanxi, China, start from 2007,sell to Mid East(27.00%),South America(25.00%),Southeast Asia(23.00%),Africa(10.00%),Central America(5.00%),Domestic Market(3.00%),North America(2.00%),South Asia(2.00%),Western Europe(2.00%),Oceania(1.00%). We have about 5-10 professional salesmen to handle the business.
2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.What can you buy from us?
Valve Seat Boring Machine,Valve Grinding Machine,Brake Lathe,Shearing and Bending Machine,CNC Metal Spinning Machine and so on.
4.Why choose us?
AMCO puts users' actual needs in the first place. We can not only make improvement of existing machine to adapt the needs of users, but also design and manufacture new machines according to the requirements of clients.We have favorable price and excellent quality.
5. What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF;
Accepted Payment Currency:USD,EUR,JPY,HKD,CNY;
Accepted Payment Type: T/T,L/C,Western Union;
Language Spoken:English,Chinese,Spanish
6.What services can you experience from us?
Our salesman English CET 6 or above,can communicate with you in fluent English.
You can keep informed of the progress of our factory in making machines.
We will show you the complete picture of the machine before shipment, so that you can wait at ease.
Our after-sales service is very timely and will solve all your problems about the machine.
