Quick Details
-
Front tire:
-
22x7-10
-
Rear tire:
-
22x10-10
-
Engine:
-
GY6
-
Brake:
-
Hydraulic Disc Brake
Quick Details
-
Brand Name:
-
HIGHPER
-
Place of Origin:
-
Zhejiang, China
-
Color:
-
black, silver, green, gray
-
Front tire:
-
22x7-10
-
Rear tire:
-
22x10-10
-
Engine:
-
GY6
-
Brake:
-
Hydraulic Disc Brake
|
Engine type：
|
JL 4-stroke, single cylinder, air cooled
|
Displacement：
|
150cc (Wangye 200cc CVT engine optional)
|
||
|
Max.output：
|
10hp/2800rpm
|
Max. speed：
|
60km/h
|
||
|
Starting system：
|
Electric start
|
Battery：
|
12v10Ah
|
||
|
Carburetor：
|
PD24J
|
Engine oil：
|
SAE 10W/40
|
||
|
Clutch：
|
CTV
|
Gears：
|
D-N-R
|
||
|
Driveline / Driving wheel：
|
Chain drive / Dual rear wheels drive
|
Suspension, F / R：
|
Dual A-arm / Thru-shaft with shocks dual A-arm
|
||
|
Brakes, F / R：
|
Hydraulic disc brake
|
Tires, F / R：
|
22*7-10/22*10-10
|
||
|
Fuel capacity：
|
1.75 gal (6.6L)
|
Weight, G.W. / N.W.：
|
295 kg/ 240 kg
|
||
|
Max. loading：
|
500 lbs (227kg)
|
Wheelbase：
|
1800 mm
|
||
|
OA L x W x H：
|
2480*1220*1520 mm
|
Height to seat：
|
530 mm
|
||
|
Min. ground clearance：
|
160 mm
|
Carton size：
|
2300*1250*870mm
|
||
|
Container loading：
|
|
8pcs/20FT, 27pcs/40HQ
|
|
||
