Quick Details
-
Model Number:
-
AHC15A
-
Max. Current:
-
16A
-
Voltage Rating:
-
AC220V 50/60Hz
-
Switch Power:
-
16A 250Vac / 10A 250Vac
-
Hysteresis:
-
less than 2sec/ day
-
Switch Contact:
-
1 changeover switch
-
Current:
-
15A
-
Power Consumption:
-
5VA(max)
-
On/Off Operation:
-
18 on &18 off, 18 times pluse
-
Certification:
-
none
Quick Details
-
Max. Voltage:
-
250VAC
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
CG
-
Model Number:
-
AHC15A
-
Max. Current:
-
16A
-
Voltage Rating:
-
AC220V 50/60Hz
-
Switch Power:
-
16A 250Vac / 10A 250Vac
-
Hysteresis:
-
less than 2sec/ day
-
Switch Contact:
-
1 changeover switch
-
Current:
-
15A
-
Power Consumption:
-
5VA(max)
-
On/Off Operation:
-
18 on &18 off, 18 times pluse
-
Certification:
-
none
Product Display
| Model | AHC15A |
| Operating Voltage | 110V / 220V / 12V-24V |
| Power range | 85~110% |
| Resistive load switching capacity | 25A / 16A / 25A |
| Power consumption | <1W/ <2W / <1W |
| Display | LCD |
| Set switch | 16 on and off 16 times |
| Min.switching time | 1min |
| Timing range | 1min~168hour |
| Timing error | < ±0.5s per day at 25℃ |
| Electrical life | 10^5 |
| Mechanical life | 10^7 |
| Ambient temperature | -25℃ ~ +60℃ |
| Relative humidity | <95% |
| Storage time | 60days;5years |
| Mounting |
dinr rail 35mm;panel |
| Weight |
160g |
| Outline dimension |
87*36*65mm |
