Quick Details
-
Model Number:
-
DPS210
-
Range of measure:
-
-0.100MPa~1.000MPa
-
Measure accuracy:
-
≤±2% F.S(Ambient temperature 25℃)
-
Display:
-
Double LCD display
-
Status display:
-
4-digital measurement value
-
display model:
-
adjustable backlight ,4 groups of display models
-
Analog output:
-
1~5V or 4~20mA
-
Transistor output:
-
NPN or PNP
-
port size:
-
External R1/8 ,NPT1/8, G1/8 option,internal thread M5
-
Response time:
-
adjustable:2.5ms,20ms, 100ms,500ms,1000ms,2000ms
Quick Details
-
Whether the smart:
-
Yes
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
RFS
-
Model Number:
-
DPS210
-
Range of measure:
-
-0.100MPa~1.000MPa
-
Measure accuracy:
-
≤±2% F.S(Ambient temperature 25℃)
-
Display:
-
Double LCD display
-
Status display:
-
4-digital measurement value
-
display model:
-
adjustable backlight ,4 groups of display models
-
Analog output:
-
1~5V or 4~20mA
-
Transistor output:
-
NPN or PNP
-
port size:
-
External R1/8 ,NPT1/8, G1/8 option,internal thread M5
-
Response time:
-
adjustable:2.5ms,20ms, 100ms,500ms,1000ms,2000ms
Specification
|
Model
|
DPS-201 compound
|
DPS-210 positive
|
|
|
Range of measure
|
-100kPa ~100kPa
|
-0.100MPa~1.000MPa
|
|
|
Withstand pressure
|
500Kpa
|
1.5MPa
|
|
|
Measure accuracy
|
≤±2% F.S(Ambient temperature 25℃)
|
|
|
|
Brief description
|
Double LCD display
|
LCD
|
|
|
Status display
|
4-digital measurement value, unit display , output status display
|
|
|
|
Output signal
|
NPN , PNP , 1~5V , 4~20MA
|
|
|
