ELECTRICAL CHARACTERISTICS AT STC
|
|
|
|
|
||||
|
Maximum power(Pmax)
|
460W
|
470W
|
475W
|
480W
|
||||
|
Open Circuit Voltage(Voc)
|
42.05V
|
42.38V
|
42.54V
|
42.71V
|
||||
|
Short Circuit Current(Isc)
|
13.99A
|
14.15A
|
14.23A
|
14.31A
|
||||
|
Voltage at Maximum power(Vmpp)
|
34.72V
|
35.05V
|
35.21V
|
35.38V
|
||||
|
Current Maximum power（Impp）
|
13.25A
|
13.41A
|
13.49A
|
13.57A
|
||||
|
MODULE EFFICIENCY(%)
|
21.00%
|
21.78%
|
22.01%
|
22.24%
|
||||
|
Operating Temperature
|
-40°C to +85°C
|
|
|
|
||||
|
Maximum System Voltage
|
1000VDC (IEC)
|
369W
|
373W
|
377W
|
||||
|
Fire Resistance Rating
|
Type 1(in accordance with 1703)/Class C(IEC61730)
|
|
|
|
||||
|
Maximum Series Fuse Rating
|
25A
|
|
|
|
||||
|
MECHANICAL CHARACTERISTICS
|
|
|
|
|
||||
|
Cell type
|
N type
|
|
|
|
||||
|
Number of cells
|
120(6x20)
|
|
|
|
||||
|
Module dimensions
|
1909x1134x35mm
|
|
|
|
||||
|
Weight
|
24.2kg
|
|
|
|
||||
|
Front cover
|
3.2mm,Anti-Reflflection Coating,Tempered Glass
|
|
|
|
||||
|
Frame
|
Anodized Aluminium Alloy
|
|
|
|
||||
|
Junction box
|
IP68 Rated
|
|
|
|
||||
|
Cable
|
TÜV 1×4.0mm2,Length:300mm or Customized Length
|
|
|
|
||||
|
Connector
|
PV Connector (compatible)
|
|
|
|
||||
|
TEMPERATURE CHARACTERISTICS
|
|
|
|
|
||||
|
Nominal Operating Cell Temperature (NOCT)
|
|
|
45°C±2°C
|
|
||||
|
Temperature Coeffiffifficients of Pmax
|
|
|
-0.38%/℃
|
|
||||
|
Temperature Coeffiffifficients of Voc
|
|
|
-0.31%/℃
|
|
||||
|
Temperature Coeffiffifficients of Isc
|
|
|
0.06%/℃
|
|
||||
|
PACKAGING
|
|
|
|
|
||||
|
Standard packaging
|
|
|
31pcs/pallet
|
|
||||
|
Module quantity per 20’container
|
|
|
324pcs
|
|
||||
|
Module quantity per 40’container
|
|
|
744pcs(HQ)
|
|
||||
