Quick Details
-
Power:
-
48V/60A
-
Min. Lifting Height:
-
330mm
-
Table Size:
-
2.44m *0.90m
-
Overall Dimensions:
-
8.72m*2.49m*2.56m
-
Weight:
-
9200 kg
-
Max.Working Height:
-
21.45m
-
Max.Platform Height:
-
19.45m
-
Max.Horizontal Reach:
-
12.05m
-
Ground Clearance:
-
330mm
-
Wheelbase:
-
2.52m
-
S.W.L (Unrestricted):
-
250kg
-
Max. Occupants:
-
3
-
Turning Radius (Inside/Outside):
-
1.87m/3.22m
-
Travel Speed (Stowed):
-
≤6.1km/h
-
Gradeability:
-
45%
Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
Hunan, China
-
Brand Name:
-
ZOOMLION
-
Power:
-
48V/60A
-
Min. Lifting Height:
-
330mm
-
Table Size:
-
2.44m *0.90m
-
Overall Dimensions:
-
8.72m*2.49m*2.56m
-
Weight:
-
9200 kg
-
Max.Working Height:
-
21.45m
-
Max.Platform Height:
-
19.45m
-
Max.Horizontal Reach:
-
12.05m
-
Ground Clearance:
-
330mm
-
Wheelbase:
-
2.52m
-
S.W.L (Unrestricted):
-
250kg
-
Max. Occupants:
-
3
-
Turning Radius (Inside/Outside):
-
1.87m/3.22m
-
Travel Speed (Stowed):
-
≤6.1km/h
-
Gradeability:
-
45%
High quality ZA20JE Electric Cherry Picker 20M
Zoomlion articulating boom lifts offer high capacity, great outreach and easy maintenance. The larger work envelope provides you with access to those hard-to-reach places. Electric articulating boom lifts are environmentally friendly with zero emissions, suitable for sensitive work environments.
ZA20JE is an electric articulating boom lift. It adopts a center layout and has a great structural rigidity. Excellent energy management system gives longer running time and improves battery life. The accurate and efficient AC drive system provides strong power and smooth control. Advanced dual control system (valve control + pump control) offers an energy-saving and efficient operation. With low noise, zero emissions and easy maintenance, this boom lift is ideal for indoor applications.
| Electric Articulating Boom Lifts | |
| Comply with CE/ANSI/GB Standard | |
| Model | ZA20JE |
| Size | |
| Work Height | 21.45m |
| Platform Height | 19.45m |
| Horizontal Outreach | 12.05m |
| Up and Over Height | 8.25m |
| A - Stowed Length | 8.72m |
| B - Stowed Width | 2.49m |
| C - Stowed Height | 2.56m |
| D - Platform Length | 1.83m |
| E - Platform Width | 0.76m |
| F - Wheelbase | 2.52m |
| G - Ground Clearance | 330mm |
| Performance | |
| Platform Capacity | 250kg |
| Drive Speed | 6.1km/h |
| Gradeability | 45% |
| Axles Oscillation | 200mm |
| Turning Radius (Inside) | 2.78m |
| Turning Radius (Outside) | 5.49m |
| Swing | 360° continuous |
| Platform Rotation | ±90° |
| H-Tail Swing | 0.6m |
| Max. Working Slope | 3/5° |
| Max. Wind Speed | 12.5m/s |
| Power | |
| Battery | 24×2V/440Ah |
| Charger | 48V/60A |
| Drive Motor | AC 32V |
| Lift Motor | AC 32V |
| Auxiliary Power | 12V DC |
| Hydraulic Tank Capacity | 75L |
| Tire | |
| Type | 33x12 D610 Foam-filled Tires |
| Weight | |
| Gross | 9200kg |
| Highlights | |
| Provide a work height of 21.50 m and lift capacity of 250 kg | |
| Fast lift system directly lowers the boom from the highest position to the ground without folding the boom | |
| Accurate and efficient traveling AC drive system and on-board motion AC drive system provide strong power, stable control and maintenance-free motor. | |
| Independent auxiliary power system for more secure applications | |
| Features | |
| Standard Features | |
| Proportional control | |
| All motion alarm | |
| Flashing amber beacon | |
| Self-closing entry gate | |
| Emergency descent system | |
| Emergency stop button | |
| Auto-leveling system | |
| On-board diagnostic system | |
| Over tilt protection system | |
| Oscillating axle | |
| Load sensing system | |
| 4.3' LED display | |
| Horn | |
