Float Water Level Switch Sensor M8 M10 Threads PP Plastic 10w 50w Plastic Float Level Switch 24 v dc Reed Sensor Float Switch

Float Water Level Switch Sensor M8 M10 Threads PP Plastic 10w 50w Plastic Float Level Switch 24 v dc Reed Sensor Float Switch

FOB Reference Price: Get Latest Price

≥10 Pieces

US $1.99

≥1000 Pieces

US $1.69

≥5000 Pieces

US $1.59

≥10000 Pieces

US $1.49

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Brand Name:: SAIER

Model Number:: SEN-PPi35

Material:: PP material, PP Plastic

Mode:: float switch

Color:: White

Used Medium:: Water and Liquid that has no Damage to the Float

Switching Power:: 10W, Normally Open,(NO), can Custom Made 70W & Normally Close

Voltage/electric current:: DC110V, ≤0.5A, DC220V, ≤1.0A

Rated voltage:: ≤DC24V(for high voltage use, access intermediate relay)

Output Signal:: Switch Signal

Fix screw:: M8/M10, Floating Diameter 24mm

Installation method:: Vertical Entry 35mm, 125mm, 230mm

Switching response time:: 0.2ms

Quick Details

Grade:: DIY, Industrial

Warranty:: 1 Year

Place of Origin:: Guangdong, China

Brand Name:: SAIER

Model Number:: SEN-PPi35

Material:: PP material, PP Plastic

Mode:: float switch

Color:: White

Used Medium:: Water and Liquid that has no Damage to the Float

Switching Power:: 10W, Normally Open,(NO), can Custom Made 70W & Normally Close

Voltage/electric current:: DC110V, ≤0.5A, DC220V, ≤1.0A

Rated voltage:: ≤DC24V(for high voltage use, access intermediate relay)

Output Signal:: Switch Signal

Fix screw:: M8/M10, Floating Diameter 24mm

Installation method:: Vertical Entry 35mm, 125mm, 230mm

Switching response time:: 0.2ms

Float Water Level Switch Sensor M8 M10 Threads PP Plastic 10w 50w Plastic Float Level Switch 24 v dc Reed Sensor Float Switch

Product Description

Product Name	PP plastic vertical mount water tank float level switch control
Material	PP plastic
Connection Size	M10
Style	Normally opened, vertical mounted, we also can custom made normal closed
Contact Capacity	AC220v/1A; DC24V/0.5A
Function	Float Switch, apply to level control and alarm of all kinds of industry such as electronic, electric power, chemical, water treatment, water supply and drainage.

The working principle of PP vertical float level switch is direct and simple. Set one point or multipoint of magnetic switch in sealed unmagnetic metal or industrial plastic tube. Fix the float with inner magnetic system to a certain place of magnetic switch in the pipe and let the float drift up and down; utilize the inner magnetic system in the float to trigger the open and close of magnetic switch to operate and control the liquid level.
