Quick Details
-
Model Number:
-
3081A
-
Brand Name:
-
XF or OEM
-
Port Size::
-
Female G3/4" 1"
-
Certifications::
-
CE, ROHS, ISO, TUV
-
Quality warranty::
-
2 years
-
Working Pressure:
-
0.2-10bar(2.9-145 )PSI
-
Medium Temperature:
-
-5~80℃
-
Protection Class:
-
IP65
-
Voltage available::
-
12VDC;24VDC;12VAC;24VAC;110/120VAC; 220/230VAC;Pulse6-24VDC
-
Body material::
-
Nylon Reinforced
-
Seal ring material::
-
NBR
Quick Details
-
Port Size:
-
3/4", 1"
-
Warranty:
-
1 years
-
Place of Origin:
-
Zhejiang, China
-
Model Number:
-
3081A
-
Brand Name:
-
XF or OEM
-
Port Size::
-
Female G3/4" 1"
-
Certifications::
-
CE, ROHS, ISO, TUV
-
Quality warranty::
-
2 years
-
Working Pressure:
-
0.2-10bar(2.9-145 )PSI
-
Medium Temperature:
-
-5~80℃
-
Protection Class:
-
IP65
-
Voltage available::
-
12VDC;24VDC;12VAC;24VAC;110/120VAC; 220/230VAC;Pulse6-24VDC
-
Body material::
-
Nylon Reinforced
-
Seal ring material::
-
NBR
Products Name: Battery Driven Solenoid Valve for Irrigation Controller
Features:
1) Option of without manual, with manual or flow control.
2) Valve body made of Aging-proof Corrosion-Resistant Reinforced Nylon for the long life duration.
3) Rugged synthetic rubber diaphragm provide the lead-proof seal.
4) Special valve configuration with the self-cleaning function, debris-tolerant.
5) Self-aligning bonnet permits fast and easy maintenance.
6) High-flow, low-friction-loss design.
Electrical Specifications
1) Solenoid: 24 VAC.
2) Inrush volt-amp: 24 VAC - 11.50 VA.
3) Inrush current: 0.34 amp.
4) Hold ng volt-amp: 24 VAC - 5.75 VA.
5) Holding current: 0.2 amp.
Application
These durable, heavy-duty commercial valves offer a selection of key features designed to provide reliable, cost-effective performance under the most challenging.
Related products:
solenoid series
valve box & quick coupling water valve series
Structure picture:
Installation ang working picture:
packing:
Shipping:
Our services:
1. To provide professional technical guidance and design solution FOC
2. Strict quality control system and rich manufacturing to make sure the high-quality products.
3. Competitive costs supported by stable raw materials supplier.
4. Strong overseas sales team to assist customers to develop sales strategy
5. Fast, efficient and professional online service,like email, skype, whatsapp tools.
6. Complaint to our general manager (gm2cnseninger.com) if not satisfied with anything, ensure timely reply within 24 hours
7. Multilingual communication services (English, Spanish, Japanese etc.)
8. OEM/ODM services.
