1、High sensitivity：CHTS-6000 is to determine the total sulfur content by ultraviolet fluorescence method. Improve the ability of anti-jamming, to avoid complicated operation of titration pool and factors of instability which used Coulometry. So the sensitivity of the instrument is greatly improved. The key components of the system use imported components to protect the detector light leakage and steam leakage and makes the machine has a reliable guarantee.
2、Standards：
SH/T 0689－2000
GB/T 35582
ISO20729-2017 replaces GB/T 11060.8-2012
EN ISO 20846:2012
GB/T 34100-2017
ISO 20846－2011
ASTM D6667-2010
BS EN 15486－2007
ASTM D7183
GB/T 11141－2014
ASTM D5453－2016
GB/T 17930－2016
DB51/T 1689
GB/T 19147－2016
YB/T 5022－2016
3、System configuration：
Standard configuration
Printer＋Computer＋CHTS-6000＋Liquid injector
Other optional parts
Solid injector、Gas injector
4、Easy to operate：
Based on Windows (10, 7 , XP , Me, 98 ) Chinese user interface to make the operation more convenient and fast.. You only need to click the mouse, and it can complete all of the parameter settings. The data collecting, processing, storage and printing controlled by computer.
GCTS-6000 technical parameters
Basic parameters：Sample types：Solid, Gas and Liquid
Method of determination: Ultraviolet fluorescence method（S）
Sample injection quantity：solid：1-90mg; Liquid：2-50μL; Gas：1-50mL
Measuring range：0.05 ～20000 ppm(mg/L)（High concentration should be diluted）
Measuring accuracy：
Concentration values (ppm)
RSD(％)
＜1 10
＜1 10
1～10
8
10～100 5
>100 3
Temperature range：room temp～1300℃
Temperature-controlled precision：±1℃
Test sample time：About 2 min
Air supply requirements：Ar：Above 99.9% ；O₂：Above 99.9%
Power supply：AC220V±22V，50Hz±0.5Hz，1500 W
Size：500(L)*490(W)* 530（H)mm
Weight：50kg
10～100 5
>100 3
Temperature range：room temp～1300℃
Temperature-controlled precision：±1℃
Test sample time：About 2 min
Air supply requirements：Ar：Above 99.9% ；O₂：Above 99.9%
Power supply：AC220V±22V，50Hz±0.5Hz，1500 W
Size：500(L)*490(W)* 530（H)mm
Weight：50kg
