Quick Details
-
Warranty:
-
25-years
-
Brand Name:
-
Sunpal
-
Model Number:
-
SP465M-72HB
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2094*1038*35mm
-
Cell Type:
-
Mono PERC Half Cell
-
Backsheet:
-
Black PCB Board
-
Packing:
-
660Pcs/40'Container
-
Material:
-
Mono-crystalline Silicon
-
Application:
-
Solar Home System
-
Solar cell:
-
A-grade black cell
-
Frame:
-
Black Anodized Aluminium Alloy
-
Keyword:
-
Black Monocrystalin Solar Panel
-
Color:
-
Customized Color
-
OEM Order:
-
Accept Customized Solar Panel
Quick Details
-
Cell size:
-
166mmx166mm
-
Type:
-
PERC, Half Cell, All Black
-
Panel Efficiency:
-
21.4%
-
Warranty:
-
25-years
-
Brand Name:
-
Sunpal
-
Model Number:
-
SP465M-72HB
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2094*1038*35mm
-
Cell Type:
-
Mono PERC Half Cell
-
Backsheet:
-
Black PCB Board
-
Packing:
-
660Pcs/40'Container
-
Material:
-
Mono-crystalline Silicon
-
Application:
-
Solar Home System
-
Solar cell:
-
A-grade black cell
-
Frame:
-
Black Anodized Aluminium Alloy
-
Keyword:
-
Black Monocrystalin Solar Panel
-
Color:
-
Customized Color
-
OEM Order:
-
Accept Customized Solar Panel
Product Description
Electrical Characteristics:
|
Cell Orientation
|
144（6*24）
|
|
Glass
|
3.2mm coated tempered galss
|
|
Frame
|
Anodized aluminum alloy frame
|
|
Weight
|
23.5kg + 3%
|
|
Dimension
|
2094×1038×35mm
|
|
Power Output Tolerance
|
0~+5W
|
|
Max. System Voltage
|
DC1500V(IEC)
|
|
Model Number
|
SP440M-72HB
|
|
SP445M-72HB
|
|
SP450M-72HB
|
|
|||||
|
Testing Condition
|
STC
|
NOCT
|
STC
|
NOCT
|
STC
|
NOCT
|
|||||
|
Maximum Power (Pmax/W)
|
440
|
332
|
445
|
336
|
450
|
340
|
|||||
|
Open Circuit Voltage (Voc/V)
|
49.2
|
46.4
|
49.4
|
46.6
|
49.6
|
46.8
|
|||||
|
Short Circuit Current (Isc/A)
|
11.39
|
9.17
|
11.46
|
9.23
|
11.53
|
9.29
|
|||||
|
Voltage at Max Power (Vmp/V)
|
40.6
|
38.3
|
40.8
|
38.5
|
41
|
38.7
|
|||||
|
Current at Max Power (Imp/A)
|
10.84
|
8.67
|
10.91
|
8.73
|
10.98
|
8.79
|
|||||
|
Module Efficiency(%)
|
20.25
|
|
20.48
|
|
20.71
|
|
|||||
|
Temp Coefficient of Isc
|
+0.048%/°C
|
|
|
|
|
|
|||||
|
Temp Coefficient of Voc
|
-0.270%/°C
|
|
|
|
|
|
|||||
|
Temp Coefficient of Pmax
|
-0.350%/°C
|
|
|
|
|
|
|||||
|
Model Number
|
SP455M-72HB
|
|
SP460M-72HB
|
|
SP465M-72HB
|
|
|||||
|
Testing Condition
|
STC
|
NOCT
|
STC
|
NOCT
|
STC
|
NOCT
|
|||||
|
Maximum Power (Pmax/W)
|
455
|
344
|
460
|
348
|
465
|
352
|
|||||
|
Open Circuit Voltage (Voc/V)
|
49.8
|
47
|
50
|
47.2
|
50.2
|
47.4
|
|||||
|
Short Circuit Current (Isc/A)
|
11.6
|
9.35
|
11.67
|
9.41
|
11.74
|
9.47
|
|||||
|
Voltage at Max Power (Vmp/V)
|
41.2
|
9.35
|
41.4
|
39.1
|
41.6
|
39.3
|
|||||
|
Current at Max Power (Imp/A)
|
11.05
|
8.85
|
11.12
|
8.91
|
11.18
|
8.96
|
|||||
|
Module Efficiency(%)
|
20.94
|
|
21.17
|
|
21.4
|
|
|||||
|
Temp Coefficient of Isc
|
+0.048%/°C
|
|
|
|
|
|
|||||
|
Temp Coefficient of Voc
|
-0.270%/°C
|
|
|
|
|
|
|||||
|
Temp Coefficient of Pmax
|
-0.350%/°C
|
|
|
|
|
|
|||||
Market Certificate:
